Characteristics
1. The arched tube plate and screw thread smoke tube build up the boiler barrel so that the boiler has high heat transfer efficiency, boosts fast, strong output and the smoke tube is hard to accumulate dust, these solve the problem of tube plate crack.
2. Eliminate the stagnant water area at the bottom of the boiler barrel, improve the water recycling effect, prevent the boiler barrel bottom bulge.
3. All welding combining are processed by large mechanical and high temperature region bundle special processing, to ensure the welding quality and service life. Easy burning and adapt to various fuel such as: soft coal, anthracite coal and biofuels.
4. Compact structure, small size, saving construction investment, easy to install, can run after connecting the valve, water, electricity and pipeline.
5. Stable operation, easy to adjust, unique design of air prevention, can bank up a fire for a long time.
6. It has a function of dust reduction, dust emission conforms to the environment standard.
Specification
Model | Evaporation(t/h) | Steam pressure(mpa) | Steam temperature(℃) | Designed efficiency |
DZH0.5-1.0-AII | 0.5 | 1.0 | 184 | ≥80% |
DZH1-1.0--AII | 1 | 1.0 | 184 | ≥80% |
DZH1-1.25--AII | 1 | 1.25 | 193 | ≥80% |
DZH2-1.0-AII | 2 | 1.0 | 184 | ≥81% |
DZH2-1.25-AII | 2 | 1.25 | 193 | ≥81% |
DZH4-1.25-AII | 4 | 1.25 | 193 | ≥82% |
DZH4-1.6-AII | 4 | 1.6 | 201 | ≥82% |
