High Power 136-174MHz VHF Circulator for Communication Repeater
Product sourcing details
High Power 136-174MHz VHF Circulator for Communication Repeater delivers superior RF performance with 100W forward power handling and 50W reverse. Featuring low 0.5dB insertion loss, 22dB isolation, and 1.2 max VSWR, this SMA-F coaxial circulator ensures reliable signal routing in telecom infrastructure, radar, and wireless systems. Designed for military, space, and commercial use, it operates from -30°C to +70°C. Includes one-year warranty.
- Minimum Order
- 1
- Place Of Origin
- China (Mainland)
- FOB Price
- USD $180.00 / Piece
- Packaging
- 12pcs each box
- Delivery
- 8-12 Days
Specifications
45 to 270MHz – Coaxial Circulator
Design Features
- Can be dual junction or multiple for high isolation.
- High RF performance, ultra-competitive price.
- Military, space and commercial applications.
- Support one year standard warranty.
RF Characteristics
| Model Number | UIYCC6060A136T174SF |
| Freq. Range(MHz) | 136 ~ 174 |
| Insertion Loss Max(dB) | 0.5 |
| Isolation Min(dB) | 22 |
| VSWR Max | 1.2 |
| Forward Power(W) | 100 |
| Reverse Power(W) | 50 |
| Connector Type | SMA-F |
| Temp.(°C) | -30 ~ +70 |
Other Related Products
- RF Isolators
- RF Circulators
- Attenuator/Termination
- RF Filters
- Power Divider/Splitter
- Duplexer/Triplexer
- TX RX Combiner/Splitter
- Hybrid Combiner
- Directional Coupler
- Waveguide to Coaxial Adapter
Applications
- Radar System
- Telecom Infrastructure
- Microwave Radio Systems
- Communication Systems
- Wireless Radio Systems
- R&D labs
- Public Address System Radio Transmitter
- Biomedical Instrumentation
If you have any customized inquiries, please contact us promptly.
