The SUGA S80 Carbon Arc Weathering Tester is a specialized environmental simulation instrument designed to evaluate the lightfastness and weather resistance of materials using a sunlight-type carbon arc lamp. By utilizing a configuration of eight carbon arc rods (four pairs) across the top and bottom of the chamber, the system provides up to 78 hours of continuous, high-intensity illumination. This tester allows you to replicate the destructive effects of solar radiation and moisture, offering automated cycles of light exposure and water spray to accelerate the aging process of non-metallic materials, coatings, and automotive components.

Applications

The SUGA S80 Carbon Arc Weathering Tester utilizes eight sunlight carbon arc lamps capable of providing approximately 78 hours of continuous illumination. These lamps are arranged in four sets positioned at the top and bottom of the test chamber. The system automatically performs both illumination and illumination combined with spray application.

Standards

JIS B7751 Sunlight Carbon Arc Lamp Lightfastness Tester and Weathering Tester (Enclosed Carbon Arc Lamp)

JIS A1415 Test Method for Accelerated Exposure Aging of Plastic Building Materials

JIS D0205 Test Method for Weather Resistance of Automotive Parts

JIS L0842-2004 Test Method for Colorfastness to Enclosed Carbon Arc Lamp Light

JIS L0891-2007 Test Method for Accelerated Weathering Colorfastness Using Xenon Arc Lamp or Sunlight-Type Carbon Arc Lamp

JIS K7102 Test Method for Colorfastness of Plastics to Carbon Arc Lamp Irradiation

ASTM G153-13 Standard Practice for Testing Nonmetallic Materials Using a Closed Carbon Arc Lamp

ASTM D3980 Laboratory Testing Practices for Paints and Related Materials

ASTM G23 Testing Nonmetallic Materials Using Carbon Arc Exposure Apparatus (With and Without Water)

ASTM G114 Terminology Related to Natural and Artificial Weathering Tests of Nonmetallic Materials

ASTM G151 Laboratory Light Source Acceleration Test Apparatus for Nonmetallic Materials

ASTM G152 Open Carbon Arc Lamp Aging Exposure Method for Nonmetallic Materials

ISO 4892-3 Plastics - Laboratory Light Source Test Methods

ISO 4892-1 Plastics - Laboratory Light Source Test Methods, Part 1: General Guidelines

ISO 4892-4 Plastics - Laboratory Light Source Test Methods, Part 4: Open Carbon Arc Lamp

NES M0135 Weathering and Light Resistance Testing of Synthetic Resin Components

NES M0141 Test Methods for Coated Synthetic Resins

NISSAN MO 135：Nissan Motor Corporation Material Specification for Powder Coatings

GM 9125P：General Motors Engineering Specification for Powder Coatings

FORD BO 101-1：Ford Motor Company Engineering Specification – Powder Coating Performance Requirements

Chrysler LP-463PB-16-01：Chrysler Engineering Material Specification for Powder Coating Systems

Features

Extended Testing Capability: The ultra-long-life carbon rods allow for 78 hours of uninterrupted testing, significantly reducing the downtime required for rod replacement compared to standard systems.

Simultaneous Exposure: The unique top-and-bottom arc configuration ensures uniform distribution of radiant energy across all 70 sample positions.

Automated Weathering: You can program complex sequences of light and rain (front spray) to simulate specific regional climates or seasonal changes.

Flexible Configurations: The system is available in specialized versions, including the SL80 for low-temperature requirements and the S80D for dew-cycle (darkness/moisture) simulation.

High Precision Control: The integrated system maintains strict tolerances for Black Panel Temperature (BPT) and Relative Humidity (RH), ensuring repeatable and reproducible results.

Parameters

Parameter	Specification
Light Source	4 pairs of ultra-long-life carbon arc rods
Continuous Illumination Time	78 hours
Voltage/Current	50±2 V, 60±2 A
Test Modes	Light only, light + front spray (rain)
Temperature Range	63±3°C BPT, 30–70±5% RH
Sample Capacity	Up to 70 pieces (150×70×1 mm)
Dimensions	136 cm (W) × 135 cm (D) × 226 cm (H), 560 kg

Accessories

Carbon Arc Rods: High-purity sunlight-type carbon rods for spectral stability.

Glass Filter Set: Interchangeable filters to simulate indoor (behind window glass) or outdoor exposure.

Black Panel Thermometer (BPT): Standard sensor for monitoring specimen surface temperature.

Specimen Holders: Stainless steel clips designed for standard $150 \times 70\text{mm}$ samples.

Purified Water System Interface: Connection kit for intake of deionized water for spray cycles.

Exhaust Venting Kit: Includes stainless steel ducts and plastic extension tubes.

Test Procedures

1. Equipment Installation

‌Location Placement‌: Choose a well-ventilated area away from heat sources.

‌Water Pipe Connection‌: Connect the inlet to the water purifier and the outlet to the outdoors, ensuring the water level remains below the drain outlet.

‌Air Duct Installation‌: Secure the stainless steel air duct, cover it with a plastic extension tube, and position the exhaust vent outward.

‌Filter Installation‌: Tilt the filter into the lamp holder and align it with the mounting bracket.

‌Install Lamp Tube: Connect accessories, insert into filter, and tighten screws.

2. Program Setup

‌Power On: Enter the main menu.

‌Select Filtration System: Press DATA → Filtration System, then choose Indoor/Outdoor Standard.

‌Set Program: Enter “Program Design” to configure program number, mode, irradiation intensity, temperature, humidity, and duration.

‌Run: Press the START button.
