Scraper Grinding Machine
Product sourcing details
Maximize blade performance with the Dekaisheng Scraper Grinding Machine. This fully automatic, PLC-controlled grinder handles blades up to 200mm wide and 130mm thick, achieving a grinding accuracy of 0.005 mm/m and surface roughness ≤0.4 micrometer. Featuring Siemens/Mitsubishi controls, linear guides, and adjustable grinding speeds, it's ideal for paper, printing, and packaging industries. Made by leading papermaking knife manufacturer Dekaisheng.
- Place of Origin
- China
- Packaging
- wooden case
Supplier: Kunshan Dekaisheng Edge Mold Co.,Ltd
Purchasing information
- Minimum order
- 1
- Lead time
- 35 Days
Please confirm with the supplier: Model / reference, Key specifications / compatibility, Samples, Export markets, Supply capacity.
Specifications
Usage：
Our commpanydevelops and produces fully automatic and speed adjustable blade grinder with frequency converter and plc programming control system. It has an independent computer operation desk, high degree of automation, one of the most advanced CNC blade grinding machines in China. The equipment adopts high-quality carbon structure and processed gantry
structure body; grinding head transmission mode is rolling linear guided transmission; cooling water is sprayed from the middle of the grinding wheel, which makes the cooling effect better; the grinding head movement and the speed of the grinding wheel are controlled by imported frequency converter, and the speed is adjustable at will within the specified range.
| Item | unit | Specifications |
| Maximum blade width for grinding | mm | 200 |
| Maximum blade thickness | mm | 130 |
| Scraper blade capacity | pieces | 5-40 |
| Angle of blade edge | degree | 0°-90° |
| Grinding accuracy of blade edge | mm/m | 0.005 mm /m |
| Surface roughness of the cutting edge | micrometer | ≤0.4 |
| Bench drive | Siemens//Mitsubishi Inverter Motor Drive | |
| Bench sliding surface | Taiwan HIWIN linear guides and sliders | |
| Bench Reciprocation | Rack and gear transmission | |
| Bench move speed | m/min | 0-25m |
| Bench drive | Inverter motor speed control | |
| Abrasive flow rate | Liter/min | 60-90L |
| Electrical protection class | ≥IP55 | |
| Digital programmable display system (PLC) | Siemens//Mitsubishi PLC | |
| 10" LCD display | Siemens//Mitsubishi Touch 10 inch | |
| Digital grinding program and grinding mode | Grinding program can be set automatically | |
| Mechanical chuck size | mm | φ320mm |
| Grinding wheel and direction of rotation | piece | φ 300* φ 250 * 100//clockwise |
| Feed of rough grinding wheel | mm | 0.01-0.2mm |
| Maximum accuracy of each feed of fine grinding wheel | mm | 0.001-0.1mm |
| Grinding wheel linear speed | m/s | 23m/s |
| Total machine power | kw | 13.25kw |
| Power supply voltage | v | Three phase 380V |
| Power frequency | hertz | 50HZ |
| Speed of grinding head | rpm | 1460 |
| Motor power of grinding head | kw | 11kw |
| Vertical feed of grinding head | mm | 300 |
| Founded in 1994 in Kunshan, Dekaisheng is a high-tech enterprise of high-end paper cutting blades. It is the leading manufacturer of papermaking knives in China in terms of scale and
category. Established in 2006, Kunshan Dekaisheng Investment company is committed to providing high quality cutting blades for industrial use. The products mainly include household tissue knives, pulp blades, cultural paper baldes, industrial paper knives, special customized machine knives, grinding equipment and other series of products. These products are widely used in paper making, printing, packaging, metallurgy and other industrial fields. The company has standardized management and strong technical force. The R&D team has more than 20 years of industry experience, and the founding team is from the world-renowned cutting tools manufacturers. We have successively introduced cutting tool production technology, equipment and imported materials from Japan, Germany, France, the United States and Sweden. With advanced equipment, superb craftsmanship, the performance parameters of the product is far beyond the level of the industry. The perfect technical guarantee system and strict quality inspection and control ensure that each blade with precision quality. Since its inception, the company adheres to the business philosophy "quality first, customer first", business purpose of branding and specialization, service commitment "timely delivery, good quality, door-to-door delivery, three guarantees of quality". Dekaisheng is committed to "comprehensive cutting technology and sincere customer service" to provide the most competitive solutions and quality products for global users. |
