FD-15T metal threading machine conduit pipe threading machine

Product sourcing details

The FD-12T Industrial Hydraulic Thread Rolling Machine delivers precise and efficient thread forming. Featuring automatic feeding, adjustable speed, and 120KN max rolling pressure, it handles working diameters of 2-20mm and thread pitches of 0.4-2.5P. Easy to operate and maintain, with CE and ISO9001-2008 certification. Ideal for high-volume production.

Outside diameter of rolling die
135-178mm
Spindle speed
28/35/45/56rpm
Thread length
In feed or Thru feed
Thread pitch
0.8-5mm
FOB Price
USD $10,850.00 / Piece
Place of Origin
china
Working diameter
4-60mm
Thickness of rolling die
120mm
Packaging
Wooden case,1 set in 1 case

Supplier: Feda Industry Co., Ltd

Purchasing information

Minimum order
1
Lead time
20-35 Days

Please confirm with the supplier: Model / reference, Key specifications / compatibility, Samples, Export markets, Supply capacity.

1. Automatic feeding with adjustable brackets

2. Speed is adjustable for different products

3. 54mm hole diameter for SKD11/DC53 thread rolling dies

4. Max. Rolling pressure is about 150KN

5. It is easy to operate and maintain the machine

6. CE, ISO9001-2008

Specification
Working diameter4-60mm
Thread pitch0.8-5mm
Thread lengthIn feed or Thru feed
Spindle speed28/35/45/56rpm
Outside diameter of rolling die135-178mm
Inside diameter of rolling die54mm
Thickness of rolling die120mm
Min.center distance between die spindles120mm
Max.center distance between die spindles240mm
Main motor5.5KW
Hydraulic motor2.2KW
Max. Rolling pressure15T
Supply voltage380V 3P 50Hz
Weight(reference)2500(KG)
Dimension(L*W*H)1560*1550*1260 mm
Package Dimension(L*W*H)1600*1540*1550 mm
