Grinding Head X

Place Of Origin: china

Minimum Order: 1

Packaging: N/A

Delivery: 15 Days

KEYING Rubber Mounted Head has a variety of specifications and granularity, accept non-standard size customization, including diameter, handle diameter, material, handle length and so on. The most prominent characteristics of KEYING rubber unitized mounted points are good grinding force, stable performance, long service life, small dust, can cooperate with the use of various high speed power tools or pneumatic tools. Mainly suitable for all kinds of casting molds, metal products, such as grooves, edges and holes concave and convex cleaning, to weld, deburr and fine polishing processing; And can be widely used to remove the resin mold burn marks, scales, rust, scratches, dents and chuck marks and other cleaning treatment; As well as being suitable for the removal of paints, electroplating and coatings, the high elasticity of the rubber material is adjusted to prevent machining scratches.

Grinding Head X

Raw Material

Aluminum Oxide, Silicon Carbide

Grit Size

60#、80#、120#、180#、240#、320#、400#、600#、Make-to-order: 800#、1500#

Shape

Cylinder, Conical, T-Type

Shank diameter

2.35mm、3mm、6mm、3.175mm、6.35mm

Handle length

30mm、35mm (other sizes can be customized)

Hardness of grinding head

High elastic grinding head, adjustable hardness (customizable).

Application

It is mainly used for edge honing of carbide tools to remove fine burr from various materials. And widely used to remove resin mold burn marks, scales, rust, scratches, dents and chuck marks cleaning treatment; Also suitable for removing paint, electroplating and coating, by adjusting the high elasticity of rubber material, thus preventing machining scratches.

Types Of Grinding Head X

Aluminum Oxide Grinding Head X (AO)

Silicon Carbide Grinding Head X (SC)

Working Principle of Grinding Head X

Reducing wear and thermal load of the workpiece can be achieved by reducing contact pressure and speed (abrasive paste/oil can be used when appropriate)

In order to avoid unnecessary tool wear and thermal load, choose to switch to coarser-grit abrasive clothes instead of increasing contact pressure to increase cutting force

lncreasing the cutting speed achieves a slightly finer surface.

Increasing the contact pressure makes the surface slightly more coarse and if you use the same grit size on soft or hard material the surface finish will look coarse on the softer material.

With high elasticity, good synchronous consumption, suitable for a variety of plane, curved surface and corner polishing.

The most prominent features of this series of products are soft polishing and fine polishing.

Used for fine grinding and polishing, can make the workpiece surface to a higher level of surface finish such as mirror.

Can cooperate with various high speed electric tools or pneumatic tools.

If you want to know more kinds of grinding wheels, grinding tools and mounted point abrasives, please visit our website.

As an abrasive supplier, we will do our best to meet all the needs of customers.

More kinds of rotary tool flap wheel, please visit our website.
