Prepainted Galvanized Steel Coil

General Description of Prepainted Galvanized Steel Coil

Prepainted galvanized coil is a product obtained by chemical surface treatment (coating) of hot-dipped galvanized steel, galvanized steel coil or aluminum, followed by baking and curing.

the total thickness of the prepainted galvanized steel coil consists of the thickness of the base steel -- coating -- primer -- topcoat -- protective coating. The top coating is 10-25 microns thick and the back coating is 5-20 microns thick. The thinner the basic steel thickness, the higher the price of PPGI steel coil, because the processing cost will be higher.

usually, the paint material is polyester (PE) and the back paint color is white and gray. Colors can be customized according to RAL color CARDS or customer samples. Can make special patterns, such as wood grain, flower pattern, camouflage, brick.

PPGI Steel Coil Specification

Product name Prepainted Galvanized Steel Coil

Material CGCC, DX51D,Q195,Q235

Zinc 20-120g

Thickness 0.13-0.8 mm

Width 600-1250 mm

Color all RAL color , as client’s request

Paint top paint : 10-30mic back paint: 5-25 mic

Paints PE, SMP, HDP, PVDF

T bend < 3T

Pencil hardness >2H

Coil ID 508/610mm

Coil weight 3-8tons

Surface glossy and matt

Glossy 30%-90%

Package standard export package (Detailed picture is as follows)

Hardness soft (normal), hard, full hard(G300-G550)

HS code 721070

Country of origin China

Business type PPGI manufacturer and PPGI supplier

Brand name Huaro

Application of Prepainted Galvanized Steel Coil

Uncoiling machine uncoiling, leveling, length fixing, the painted galvanized steel coil is cut into the desired length and width of flat PPGI plate, and the roll forming machine is used to process various styles of PPGI&PPGL roof board, such as corrugated steel plate, wave tile, Roman longtile profile.

Advantages of Prepainted Galvanized Steel Coil

you can create any shape, such as curved, rectangular, oval and tubular. Provides a variety of color range for you to choose

promote durability

provide convenient cleaning facilities

affordable maintenance

tensile properties provide sufficient strength to cover the roof, shade and shed.

As one of prepainted galvanized steel coil manufacturers and prepainted galvanized steel coil suppliers, we can offer sorts of related products for sale, if you are interested, please contact us.
