Gasoline Engine-IDSi 1300cc Training Stand

Dimension: 1500×1000×1900（L×W×H）

Operating Environment: Temperature -40℃～40℃, Humidity≤80%

Engine Type: Honda engine

Displacement: 1.3L

Engine oil grade: API, standard SG grade Storage battery: maintenance-free battery

The complete rack use square tube of 40*40*2mm thick and angle iron of international standardized profile to conduct seamless welding, its surface is dealt with high temperature spraying plastics after polishing, which is anti-corrosion, anti-aging and fastness, it is installed with universal self-locking castor on the bottom of the rack, which is convenience to teach movably.

The control panel used aluminum-plastic panel, it is painted with colorized intuitive electronic control system schematic diagram that is the same with the original car control system on the panel, and it is also equipped with operating manual and experiment instructor.

Engine assembly, engine control unit, original wiring harness, instrument assembly, coolant temperature sensor, air charge temperature sensor, restrictor control assemble, air mass meter, oxygen sensor, whole set of heat-removal mechanism, gasoline tank, gasoline pump assembly, storage battery, 5 digital voltmeter and fuel pressure gauge, panel with complete colorized circuit schematic diagram, circumscribed detective terminal, intelligent fault setting box assembly, movable rack, operation manual and experiment instructor.
