The introduction of the LED UV multi-color system has revolutionized UV curing in the metal printing industry. One LED UV lamp is installed between two color units, and three LED UV lamps and one traditional mercury lamp are installed behind the final color unit of the uv drying machine. This can greatly improve the printing speed while ensuring curing efficiency.

UV Drying Machine Specification

UV Curing unit Technical Data

Machine Dimensions(mm) 2610x1680x1600

Maximum speed (sheets/min) 90

Maximum Tinplate Width (mm) 1200

Main power 50HZ,85KW

Configurations Standard Optional

Servo stacker √

Stacker √

Receiving machine stacker electrical sheet roller 0

Review stage 0

Stacker with dual-purpose electrical sheet roller 0

UV Drying Machine Technical Performance

UV drying machine is a cold light source, no heat radiation, no ozone generation, more environmentally friendly compared to mercury lamps

UV drying machine needn\'t preheat and is ready to use

Compact shape, compact structure, can be installed without moving the machine

Lower energy consumption, 50% energy savings

RUIYUAN Printing Equipment Co. Ltd., is a professional offset printing press manufacturer, we provide metal decorating printing, drying oven for sale, offset printing press, etc. Want to know more? Contact us.

A UV curing and drying unit listed for multi-colour metal-printing lines. The source describes LED UV lamps between colour units and a combined LED UV and mercury-lamp arrangement after the final colour unit. Buyers should confirm lamp configuration, sheet format, curing dose, line integration and electrical requirements for the intended inks and production speed.

Procurement specification

Machine dimensions: Supplier-listed dimensions: 2610 × 1680 × 1600 mm.
Maximum speed: 90 sheets per minute is listed; confirm against substrate and curing-dose requirements.
Maximum sheet width: Maximum tinplate width is listed as 1,200 mm.
Electrical data: The source lists 50 Hz and 85 kW main power.
Delivery field: 15 days is shown on the listing; confirm after line-layout and configuration approval.

Listing details

The listing describes one LED UV lamp between two colour units.
Three LED UV lamps and one traditional mercury lamp are described after the final colour unit.
A servo stacker is marked as standard in the source configuration table.
The supplier describes the unit for metal decorating and offset-printing applications.
Energy and environmental benefits appear as supplier statements and are not independently verified by Mfrbee.

Buyer checklist

The following items are not verified product claims. Confirm them directly with the supplier before ordering.

Specify substrate material, thickness, sheet size, ink or coating chemistry and target line speed.
Confirm LED wavelength, irradiance, dose, lamp count, lamp life and mercury-lamp operating requirements.
Provide the existing press layout, sheet-transfer height, interfaces, ventilation and available electrical service.
Request curing tests using the intended substrate and ink, plus acceptance criteria for adhesion and finish.
Confirm installation, commissioning, operator training, warranty, spare lamps and after-sales support.
