Flat Botton Paper Bag Machine

Minimum Order: 1

Packaging: N/A

Delivery: 15 Days

This flat bottom paper bag machine is suitable for many kinds of environmental protection rollpaper such as kraft paper, butter paper, food grade film-coated paper medical paper, etc.

The automatic bag making machine is piercing, paper edge gluing, color standard length fixing ( or fixed length ), raw material forming, length fixing breaking, bottom folding, bottom gluing, forming, and other processes in one line.

This fully automatic paper bag machine adopts a motion controller and servo motor programming which is easy to operate, efficient in production and stable in operation.

Environmental protection paper bags of various specifications and sizes, such as sharp bottomed paper bags, bread bagswith windows, leisure food bags, dry fruit bags, etc can be produced by this paper bag automatic machine.

Specification of Flat Botton Paper Bag Machine

Technical parameters

Model RKJD-350 RKJD-250

Bag making speed 50-680pcs/min 50-320pcs/min

Paper Bag Length ( L ) 155-715mm 110-450

Paper Bag Width ( W ) 70-350mm 70-250mm

insert Size ( WS ) 20-120mm 20-120mm

Step Height 15/20mm 15/20mm

Paper thickness 35-80g/m² 35-80g/m²

Paper roll width 100-980mm 100-760mm

Paper roll diameter 200-1000mm 200-1000mm

Inner diameter of paper core 76mm 76mm

Total power 26KW 30KW

Working ar source >0.12m²/min 0.6MPa >0.12m²/min 0.6MPa

Total Weight 6500kg 4500kg

Overall dimensions 7300x2300x1900mm 7000x2000x1900mm

As a packing machine company, we will do our best to meet all the needs of customers.
