Flap Wheel M14 4inch

Place Of Origin: Zhejiang Province, China

Minimum Order: 1000

Packaging: Bag, box

Delivery: 3-90days

KEYING 40mm flap wheel M14 is manufactured from high-quality domestic cloth and pure imported cloth, this product uses imported binder (glue), this series of products have high performance, strong grinding force, synchronous consumption stability, long service life, minor dust, beautiful appearance, high cost performance characteristics.

Flap Wheel M14 4inch Specification:

Diameter: 4 inch=100mm

Max. RPM: 9000 RPM

Raw Materials: Aluminum Oxide(AO), Silicon Carbide(SC), Zirconia(ZR), Ceramic Aluminum Oxide Combined (CAO)

Grit Size: 40#~1200#

Shank Diameter: 3mm/6mm/3.175mm/6.35mm/8mm/10mm (Other sizes can be customized)

Flap Wheel M14 4inch Materials that can be worked:

Aluminium

Cobalt-based alloys

Other non-ferrous metals

High-temperature-resistant materials

Nickel-based alloys (e. g. Inconell and Hasteloy)

Bronze

Hard non-ferrous metal

Titanium

Copper

Soft non-ferrous metal

Brass

Stainless steel (INOX)

Grey/nodular cast iron (GG/GJL, GGG/GJS)

Annealed cast iron

Steel, cast steel

Flap Wheels with Shank

Flap wheels with Shank is suitable for grinding small area, dead angle, inner hole surface and slit gaps that difficult to reach. The Features of the abrasive clothes are various with multipurpose application capacity. It is flexible and rich in tensile strength. It could remove the burr and uneven, rough surface with fast grinding force effeciently, meanwhile, can make sure the performance result achieve a slightly finer surface. It is a good product for pre-painting or mirror finishing preparation procedure.

Advantages：

High flexibility to optimium adapation to countours

Steadly high stock removal through the entire tool life and aggressive coated abrasive resin is freed up constantly

The design of opening spaces and flat bonded make the abrasive tools can process as face-down position, so can touch closely to the edges and corners.

Flap Wheel M14 4inch Applications:

Leveling

Deburring

Surface work

Weld dressing

Structuring (matt finishing, brush matting and satin finishing)

Fine grinding in multiple steps

Flap Wheel M14 4inch Applicable Industries

Applicable Industries

■ Chemical processing industries

■ Building

■ Steelworks

■ Tool and mold processing

■ Pipeline

■ Shipping Building

■ Automotive industry

■ Aerospace, gas turbine treatment and repair

■ Machine engineering

Application Purpose

■ Leveling

■ Deburring and Welding grinding

■ Structuring Surfaces

■ Step-by-step fine grinding

Safety Warning of Flap Wheel M14 4inch

Instructions:

Please try to choose an operation indoor environment and wear protective guards and goggles.

Never exceed the recommended maximum permitted rotational speed for safety reasons.

In order to have a good stock removal rate, quality of surface, and thermal loading on the workpiece, the best performance would be with a recommended cutting speed of 15-20m/s.

Don't push and increase the pressure during the processing to achieve a finner surface looking, but try to switch to different grit flap wheels.

Safety Warning:

The clamping length between shank and grinders should be more than 15mm.

Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.
