Clean steam generator using electric energy as heating source is referred to as electric heating clean steam generator. The steam generated after the purified water is heated and evaporated by the electric heating clean steam generator, through the centrifugal separation structure that can effectively remove the water droplets and pyrogens entrained in the steam, the condensed water of the clean steam produced meets the quality indicators of USP, EP, JP and ChP on "water for injection".
This machine is suitable for production places without industrial steam, and is an ideal sterilization equipment for hospitals, pharmaceutical, catering, electronics, chemical and other industries.
Specification ofElectric Clean Steam Generator
Specification | Clean Steam Output(Kg/h) | Purified Water Consumption(L/h) | Electricity Consumption(KW) | Overall Dimension L×W×H(mm) |
CSGE50 | >50 | 65 | 48 | 1000x700x2000 |
CSGE100 | >100 | 125 | 96 | 1200×900×2500 |
CSGE200 | >200 | 250 | 192 | 1700×1000×2700 |
CSGE300 | >300 | 375 | 288 | 1900×1100×2800 |
HOW DOES ELECTRIC CLEAN STEAM GENERATOR WORKS?
Industrial steam is the most cost-effective heating source of clean steam generator.
In places without industrial steam, electric heating can be selected if conditions permit. Electric energy is converted into heat energy as an alternative energy for industrial steam.
FEATURES OF ELECTRIC CLEAN STEAM GENERATOR
01.
Precise control of clean steam output pressure and temperature, fluctuation within+5%.
02.
Clean steam pressure output range: 2-4Bar.
03.
Electric heating is adopted to convert electric energy into heat energy.
04.
PLC+HMI full-automatic control mode.
05.
Rising film/falling film, two working modes are optional.
06.
Comply with relevant requirements of WS310 supply room management specification
Pharmaceutical water purification system adopts the latest processes such as reverse osmosis and EDI. Purified water distribution system designs a complete set of purified water process in a targeted manner. The quality of purified water for pharmaceutical manufacturing meets the requirements of the current USP, EP, JP and ChP for purified water.
