Galfan Wire

Galfan Wire For Gabions, Ropes And High Security Fencing

Galfan wire is a special galvanized annealed wire

The Galfan coating provides enhanced corrosion resistance and durability for the steel wires, making Galfan coated wire well-suited for various applications, particularly in industries where corrosion protection is crucial.

Processing
Zinc-aluminum alloy coated steel (Galfan) wire is made of 6.5 mm low-carbon steel wire by drawing, high-temperature annealing, pickling and rust removing, hot-dip galvanizing with zinc-aluminum alloy.
Wire diameter ranges from 1.24mm-5.5mm.
Galfan coatings can be Al 5%, Zinc 95%, or Al10%, Zinc 90%.

Corrosion resistance: about 2-3 times that of ordinary galvanized steel wire

Coating material: Zinc aluminum alloy
Coating process: Thermal spraying

Major Products ( Classified according to wire sizes and packing forms)

Galfan steel wires in sizes 0.5 mm to 5 mm, for wire rope manufacturer

Galfan wire, material medium carbon steel wire, 95% Zn / 5% Al coated

Tensile Strength of Wire (MPa)	900	900	900
Carbon Contain	Medium	Medium	Medium
Wire Diameter (mm)	3.4	4.0	4.5
Tensile Resistance of Wire (kN)	8.2	11.3	14.3
Coating	95% Zn / 5%Al	95% Zn / 5%Al	95% Zn / 5%Al
Coating Thickness (gr/m2)	> 265	> 300	> 300

Galfan Coated Wire (Zn95% & Al 5%) Diameter 3.05 mm with Different classes of coating:

Sr	Product Size	Tensile Strength	Galfan Coating
1	Dia. 3.05mm - Galfan Class 3 coating	Max 485Mpa	Min 259g/m2
2	Dia. 3.05mm - Galfan Class 1 coating	Max 485Mpa	Min 92g/m2

Galfan Wire Coils for Galfan Gabions

Galfan wire as excellent corrosion resistant material, is mainly used for producing of wire meshes, especially galfan gabions.

Individual Galfan(zn-al alloy) Steel Wire, with 245 GSM zinc coating 95% and Aluminium Coating 5%, for welded mesh gabions.
Tensile strength: Min. 550 N/sqmm.
Wire dia required: 4mm, 4.5mm, 5mm.
Packing: In big coils 50 to 500kg.
