Mission Centrifugal Pump Magnum Spare Parts Casing
Product Quick Detail
- FOB Price
- USD $3,500.00 / Piece
- Place Of Origin
- 中国
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Description
Sandman™ Mission Centrifugal Mud Pump Casing
Tobee manufacture Mission centrifugal pumps and parts ,100% interchangeable for below model:
Mission Centrifugal pumps Magnum type 3x2x13, 2500 Supreme 3x2x13, Sandmaster 3x2x13
Mission Centrifugal pumps Magnum type 4x3x13, 2500 Supreme 4x3x13, Sandmaster 4x3x13
Mission Centrifugal pumps Magnum type 5x4x14, 2500 Supreme 5x4x14, Sandmaster 5x4x14
Mission Centrifugal pumps Magnum type 6x5x11, 2500 Supreme 6x5x11, Sandmaster 6x5x11
Mission Centrifugal pumps Magnum type 6x5x14, 2500 Supreme 6x5x14, Sandmaster 6x5x14
Mission Centrifugal pumps Magnum type 8x6x11, 2500 Supreme 8x6x11, Sandmaster 8x6x11
Mission Centrifugal pumps Magnum type 8x6x14, 2500 Supreme 8x6x14, Sandmaster 8x6x14
Mission Centrifugal pumps Magnum type 10x8x14, 2500 Supreme 10x8x14, Sandmaster 10x8x14
Sandman™ Mission Pump Interchangeable Spare Parts
1 P25PED 20618-12-1 17670 1-250-PED
2 250 Shaft 1 P25SHFT 20612-02-33 17665-001 7-250-416SS
3 250 Outboard Bearing Housing 1 P25OBBH 20624-01-01 17673 4C-250-BH
4 250 Packing Gland 1 P25PG 20622A 17659 9-250-GPA
5 250 Inboard Bearing 1 P25IBBRG 20615-1 50913-001 4B-250-BI
6 250 Water Slinger Ring 1 P25SRW 22210-1A 17691 23-250-SRW-U
7 250 Inboard Bearing Cover 1 P25IBBC 20626A 17671 2B-250-BC
8 250 Outbaord Bearing 2 P25OBBRG 20616-1 50912-001 4A-250-BO
9 250 Outboard Bearing Cover 1 P25OBBC 20617A 17866 2A-250-BC
10 250 Graphite Packing 1 P25PMSG 8264-24-OBA 17660-001 8A-250-PMSG
250 King Packing 1 P25PMSK 8474-24-1A 17660-002 8C-250-PMSK
250 Teflon Packing 1 P25PMST 8264-24-7A N/A 8B-250-PMST
250 Mechanical Seal 1 P25MS/TT 22451 17662 34A-250-MSI
11 250 Gland Bolt Assy 2 P25GABA 3701A 17686 10-250-GABA
12 250 Shaft Sleeve, Ceramic 1 P25SHSLVC 20613-21G-7A 17666-002 7A-250-SSC
13 250 Stuffing Box F/Packing 1 P25SB/PK 20614-01-30 17657-002 11-250-SBPG
250 Stuffing Box F/Mech Seal 1 P25SB/MS 22223-01-30A 17658-002 11C-250-SBMSS
14 250 2x3x13 Impeller 1 P25D233MRxxx 19204-XX-30 17650-XX-112 1225231XX
250 3x4x13 Impeller 1 P25D343MRxxx 19206-XX-30 17651-XX-112 1225341-XX
250 4x5x14 Impeller 1 P25D454MRxxx 19224-XX-30 17652-XX-112 1225451-XXX
250 5x6x11 Impeller 1 P25D561MRxxx 19121-XX-30 17653-XX-112 1225561-XXX
250 5x6x14 Impeller 1 P25D564MRxxx 19121-XX-30 17654-XX-112 1225561-XXX
250 6x8x11 Impeller 1 P25D561MRxxx 19121-XX-30 17653-XX-112 1225661-XXX
250 6x8x14 Impeller 1 P25D684MRxxx 19116-XX-30 17656-XX-112 1125681-XXX
15 250 2x3x13 Housing Assy 1 P25D233H 19203-01-30A 1769-002 142523HAS
