Heavy Hammer Crusher

Feeding Size: ≤600 - ≤1200 mm

Production Capacity: 100 - 800 t/h

Power: 132 - 560 kw

Total Weight: 16.2 - 63.6 t

Heavy Hammer Crusher Introduction:

Heavy hammer breaker, also named as single stage hammer breaker manufacturer and hammer breaker machine, is applied to crushing various raw materials in highways, high-speed railways, tunnels, large bridge, cement, metallurgy, building materials, coal, and chemical industry. The single stage hammer breaker manufacturer has large feeding size and small discharging size. The single hammer of hammer breaker machine has large weight, and the rotor speed is reasonable, which fully embodies the advantages of crushing light material with heavy hammer.

Heavy Hammer Crusher Features:

1.Large feeding size, large crushing ratio, high efficiency;

2.Simple structure, assembly and compact, light weight;

3.Uniform particle size,

4.Easy maintenance, low wear and tear;

5.Low power consumption.

Heavy Hammer Crusher Working Principle:

Main working part of heavy hammer breaker is the rotor of hammer (also known as the hammer head), and the rotor is formed by spindle, disc, pin roll and a hammer, and the rotor is driven by motor to make high-speed revolution in crushing cavity. Materials are fed from the upper feeding port into the machine, and then be crushed by impact, shear, grinding and crushing of high-speed rotating hammer. Sieve is designed in the lower part of the rotor, so crushed item less than the size of mesh size will be discharged through the sieve board, while crushed item larger than the opening size will be left on the sieve plate for continues crushing and grinding by hammer, and finally be discharged through the sieve board.
