| Finished products size | (180-220)×210mm (width is adjustable) (other sizes can be designated ) |
| Jumbo roll size | width800-1680mm 17~22g/m2×2(ply) Jumbo roll diameter ≤1200mm |
| Jumbo roll core inner diameter | 76.2mm (Other sizes can be designated) |
| machine speed | 700-800 draws/min (set as per how many lines) |
| Slitting system | Pneumatic mode point-cutting |
| Vacuum system | 11-30KW |
| Machine power | 10-40kw, (380V, 50Hz) |
| Overall size | L×W×H =7× (1.2~2.8) ×1.8m |
| Slitting system | Pneumatic point-cutting, full cutting |
| Embossment unit | steel to rubber roller, steel to steel roller |
| Embossment down roller | rubber roller, steel roller |
| Side rolling embossment | Steel to steel, independent adjustment |
| Weight of machine | 6~10T |
