Plastic Foot Valves

Minimum Order: 1

Packaging: N/A

Delivery: 15 Days

Common materials of plastic Foot Valve:

FRPP reinforced polypropylene -20°C~90°C

UPVC hard polyvinyl chloride -10°C~70°C

CPVC Chlorinated Polyvinyl Chloride -40°C~95°C

PVDF polyvinylidene fluoride -40°C~140°C

PPH polypropylene-20°C~95°C

Plastic Foot valve characteristics: lightweight, strong corrosion resistance

The plastic foot valve has a compact and beautiful appearance

Plastic foot valve body is lightweight, cost effective and easy to install

The plastic foot valve has strong corrosion resistance and a wide range of applications

Plastic foot valve material is hygienic and non-toxic

The plastic foot valve is wear-resistant, easy to disassemble, and easy to maintain

Plastic foot valve applicable fluid: water, air, oil, corrosive chemical liquid

PVC foot valves can be used for backyard ponds and even industrial applications where PVC is a suitable material.

Plastic Foot Valves Dimensions

SPRING TYPE

SIZE NPT BSPT BS ANSI DIN JIS D L H

Thd./in d1 d1 d1 d1

3/4" 14 14 26 26.7 25 26 35.4 43.5 140.6

1" 11.5 11 34 33.4 32 32 41.1 52.8 148.4

1-1/4" 11.5 11 42 42.15 40 42 48.7 53.6 150.1

1-1/2" 11.5 11 48 48.25 50 48 55.1 77.5 217.4

2" 11.5 11 60 60.3 63 60 67.4 77.5 217.4

BALL TYPE

SIZE NPT BSPT BS ANSI DIN JIS D L H

Thd./in d1 d1 d1 d1

2" 11.5 11 60 60.3 63 60 73.7 115.3 238.6

Plastic Foot Valves VS Metal Foot Valves

1. Standard:

Both plastic foot valves and metal foot valves standard are ASME, DIN, BS

2. Pressure:

Plastic foot valve's pressure is PN6, metal foot valve's pressure is Class125/150, PN10/16

3. Range of Applications (Similarity):

Standard: NPT, BSPT, BS, ANSI, DIN, JIS

Length: NPT, BSPT, BS, ANSI, DIN, JIS

Connection: Thread connected

4. Installation (Difference and Similarity):

The plastic foot valve is lighter and cheaper, which is easy to install and disassemble, plastic and metal foot valves are connected by threaded ends.

Plastic Foot Valves FAQs

What is a Foot Valve?

A foot valve is a type of check valve that only allows one-way flow. You can use foot valves when you have situations that need a pump, such as when water needs to be extracted from an underground well. Foot valves are ideal for use in pools, ponds, and wells. Their typical materials include PVC, plastic, bronze, cast iron, and stainless steel.

PVC Foot Valves Advantages

1.These foot valves prevent damage to water pumps that can occur due to dry runs, as well as stop wastage of energy.

2.Without these foot valves, the water would flow down through the pipe, back to its original source when the pump is shut off.

3.The internal balls ensure quick sealing and valve reaction as well as the flexibility to fit various types of water pump uses.

4.They are cheaper to use, as compared to other valves used to prime a pump.

5.Good quality foot valves help extend the overall lifespan of water pumps.

6.They are cost-effective and lightweight.
