Tobee® Mission Heavy Duty Centrifugal Mud Pump 6x5x14
Product Quick Detail
- FOB Price
- USD $3,500.00 / Piece
- Place Of Origin
- 中国
- Seal Arrangement
- Mechanical seal
- Sizes
- 3x2x13 to 10x8x14
- Minimum Order
- 1
- Pump Model
- 6X5X14
- Color
- customizable
- Head Pressure
- 550 feet
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
• Up to 50% more capacity from the 8 x 6 pump
• Optimum pressure at low operating speeds
• Thicker casing to extend life from wear and corrosion
• New impeller design to reduce loads and extend bearing life
• Larger, stronger shaft to reduce deflection
• Replaceable shaft sleeve in packing wear area
• Larger, long-life bearings
• Replaceable stuffing box cover
• Smoother, non-turbulent flow throughout casing
Typical Configurations:
3x2x13 6x5x14
4x3x13 8x6x11
5x4x14 8x6x14
6x5x11 10x8x14
Typical Applications:
• Mud pumping – offshore/onshore
• Solids control
• Dredging
• Leveling or Rig Platform (ballast)
• Barite, ferric oxide, and mineral oil
• Base drilling muds
• Glass fibers
• Sugar processing
• Ash or coal conveyers
• Cement
