Ice Maker Micro Switch G5W11
Product Quick Detail
- Place Of Origin
- China
- Minimum Order
- 250000000
- Packaging
- Box/Carton
- Delivery
- 4 Weeks
Specifications
Tailored ice makers with appropriate electrical load and resistance to extremely low temperatures.
Well sealed case and cover, IP67 level protection
Tight configuration, tiny contact clearance, snap action mechanism, highly sensitive detecting ability.
High durability, precision, and reliability
Widely applicated in automobiles, farming equipment, office automation, etc.
Meet the max current regulation at ENEC/UL (10A)
Ice Maker Micro Switch G5W11 Specifications
Place of Origin Guangdong, China (Mainland)
Brand Name Unionwell
Model Number G5W11 Series
Max Operating Force (at pin plunger) 200gf
Terminal Type Solder/Straight PCB/Left angle PCB/Right angle PCB
Lever Type No Lever/Simulated Roller
Circuit Code SPST-NO/SPST-NC
Certifications ENEC, UL/cUL, CQC
OEM/ODM Available
Rating W1 ENEC 0. 1A 48VDC,0. 1A 125/250VAC,40T85,5E4, u
UL 0. 1A 48VDC,0. 1A 125/250VAC, T85
W2 ENEC： 5A 48VDC, 0. 1A 125/250VAC, 40T85,5E4,u
UL:5A 125/250VAC, 5A 30VDC T85
W3 ENEC 10(2)A 125/250VAC, 0.5A 125VDC, 0. 25A 250VDC,40T85, u, 2e4
UL 10. 1A 1/10HP 125/250VAC,0.5A 125VDC, 0.25A 250VDC, T85
Operating Frequency Electrical 10~30 times/min
Mechanical 60 times/min
Contact Resistance(Intial Value) with terminal type 50mΩMax
with wire type 100mΩMax(Depends on the length of the wire)
Insulation Resistance At 500vdc, 100MΩ Min.
Dielectric Strength Between terminals AC 1000V 50-60Hz 1min
Between terminals and housing AC 1500V 50-60Hz 1min
Storage Temperature -40° C~+85° C
Strorage Humidity 85%RH Max
Protection Grade With terminal type IEC IP67 (expect terminal)
With wire type IEC IP67
Electric-shock safeguard grade Class II
Life E-Life 20,000 time~100, 000 time above (Depending on the type) 2E4~10E4 cycles (depends on P/Ns)
M-Life Over 500,000cycles or 1,000,000cycles (60cycles/min)
Unit Net Weight Approx. 7g (with terminals type and without lever)
Ice Maker Micro Switch G5W11 Related Applications
Micro switch for ice maker plays a crucial role in ensuring the efficient and safe operation of the ice maker. Its main purpose is to control the operation of the ice maker by signaling the ice
maker's control board when the ice maker bin is full or when the ice maker arm is lifted.
The unionwell switch for ice maker is typically located in the ice maker assembly and is triggered by the movement of the ice maker arm. When the ice maker bin is full, the ice cubes will push the
arm up, which in turn activates the micro switch. The ice maker micro switch sends a signal to the control board to shut off the ice maker, preventing it from making more ice and avoiding
overflowing of the ice bin.
Similarly, when the ice bin is empty or the ice maker arm is lowered, the micro switch for ice maker is released, and the control board signals the ice maker to start producing ice again.
If you're looking for a reliable and efficient way to control your portable ice maker, then the micro switch for ice maker is an essential component to consider. This small but powerful micro
switch for portable ice maker plays a crucial role in regulating the ice maker's operation.
The ice maker micro switch is responsible for detecting when the ice bin is full or empty, as well as for sensing the position of the ice maker arm. This information is then relayed to the ice
maker's control board, which in turn manages the ice-making process. With the micro switch for ice maker, you can be sure that your portable ice maker is working at peak efficiency and that you
won't have to worry about overfilling the ice bin or other issues that could damage your machine.
So if you want to keep your portable ice maker in top condition and ensure that you always have plenty of ice on hand, consider investing in a high-quality micro switch for ice maker today.
