LCD IR conference touch screen all- in-one interactive whiteboard from Shenzhen Champion New Media is a star among the same products in the market, standing out for our reliable quality and
excellent design with cost-effective price, it was widely used in many scenarios such like conference room for companies, Exhibition center, Education, Training, Traffic control center, Museum
,Airport, Metro station, etc.
Key Features for CP IR Touch Screen All-in-one Interactive Conference Board
Big screen with 4K high resolution gives best presentation for all details.
Adapting 10 points IR touch screen technology, interactive is a trend of all machinery, people can use interactive board to realize their remote conferences.
Windows & Android dual system options available, allow us to choose more useful functions.
Auto brightness adjustment function gives the interactive board broad usage in many different situations.
One press to enter energy saving model and turn to Standby model for certain time without operation makes it more eco friendly.
Finger gestures recognition function add more value for the interactive board.
Can hold 4 different devices to share screen together, with in time control or reverse control.
Shenzhen Champion New Media Technology owns unique private ultra thin design with better fitness with the whole environment, by using grade A panel combined with our rich experience, the quality of
our interactive board has gain a lot fans from all of our customers.
Why Choose Champion Conference Interactive Whiteboard
CP LCD IR interactive conference machine is widely used in conference rooms, schools, display / exhibition rooms, etc. It attracts fans by it's own excellent performance.
Compared with traditional conferences, our all-in-one interactive conference machine is far more than what we describe it as "Smart".
It contains toughened glasses / tempered glasses as protect surface with IR touch technology implemented, it will bring more fun or useful functions to everywhere it was used, with our own design
our interactive boards get very attractive appearance, ultra thin design makes the whole machine fit the environment perfectly .
For IR touch interactive Conference machine we have wide range of sizes for you to choose from , 55”, 65”, 70”, 75”, 86”, 98” are available.together you can choose Android or Windows or dual system
if you want. with other accessories including camera, projector, touch pen, micro phone, OPS pc, bracket, and remote controller, all the accessories will add more functions and fun to the
customers.
Producing Process for Conference Machine and Teaching Machine
Specification of Conference Interactive Whiteboard
Model CP-CTMIR70R CP-CTMIR55R CP-CTMIR65R CP-CTMIR75R CP-CTMIR86R
OS System CPU MSTAR 648 ARMCortex-A53 MSD6A648 Cortex A53*4
System Android 6
GPU MaliT720MP2 6 core GPU
Memory DDR4 2G
HD EMMC 16G / 32G (Optional)
Network Blue Tooth4.0 / Ethernet/ WIFI /4G (optional)
Interface Input TF*1,RJ45*1,RS232*1,AV*2, RF *1 (TV IN),SD(MINI) *1, PC(VGA) *1, HDMI *2, RJ45*1,USB2.0*2
VGA*1, VGA Audio*1,YPBPR*1
Output Touch*1,USB*2,Earphone*1, USB *1,HDMI *1, USB2.0* 1,USB3.0 * 1*Earphone *1
HDMI*2, SPDIF*1
Supported Media Image format JPEG / BMP / PNG BMP / JPEG / PNG / GIF
Audio format WMA / MP3 / M4A 8Ω5W*2 MP3/JEPG/ MPEG4/H.264/H.264/RM…. 8Ω5W*2
Vedio format RM/MPEG2/MPEG4/H.265/ RM/RMVB,MKV,TS,FLV,AVI,VOB,MOV,WMV,MP4
RMVB/MOV/MJPEG/VC1/FLV
Management Control System CMS
Software function Projection,Conference whiteboard function
Update OTA remote update / Manual Update
Screen Panel size 70" 55" 65" 75" 86"
Panel Brand LG/Sharp/BOE
Screen scale 16:09
Resolution QFHD 3840*2160
Viewing angle 89/89/89/89 (Min.)(CR≥10)
Display Model IPS ,Normally Black,Transmissive
Colors 1.07G(8-bit+FRC)
Brightness 350cd/m2 280cd/m2 300cd/m2 320cd/m2
Contrast ratio 4000:01:00
Touch System Touch Tech IR touch
Dots 10
Accuracy ±2mm
Response time 8ms
Transmittance >93%
Lifespan ≥50,000 hrs
Power Wattage Standby :1W Standby :0.5W Standby :0.5W Standby :0.5W Standby :0.5W
Max: 250W Max: 120W Max: 200W Max: 290W Max: 400W
Voltage AC100V - 240V 50Hz/60Hz
Plug type EU US AU UK
Body Protected Shell Tempered Glass
Case Cold-rolled steel plate.
Frame Aluminium
Working Environment Working Temperature 0 - 70℃ -20- 60℃
Afer-sale service Period One Year warranty lifetime maintenance
Ways Online Video support ,Training
Packing details Material Carton, Foam
Dimension (mm) 1585.5*955.9*86.5mm 1265*105*764mm 1496*105*893mm 1728*108*1030mm 1973*108*1168mm
Applications Indoor use (super market ,Hospital ,Shopping center ,School,Bank,Traffic control center etc)
Installation Rack-mounted
Languages Multiple Language Pack
OPS (Optional)
CPU Inter core I3 / I5 / I7 (Optional)
Memory DDR3 4G / 8G (Optional)
HD SSD 128G/256G (Optional)
Graphic Card Intel HD
Application Scenario of Conference Interactive Whiteboard
1. Conference room for companies: Conference format changes with new technology application, with our interactive conference machine, it can meet all your expectation about a high tech, efficient
meeting, no matter remote video conference or interactive intelligent group discussing.
2. Exhibition, Museum, Super Market etc: with big screen and high tech feature together with high resolution presenting for products, it was very widely used in many exhibition centers, Museum or
super market etc
3. Control center: With clear presentation for details and strong data visual effect LCD whiteboard was used in traffic control center, security center, etc.
4. Classrooms in school or training center: Interactive functions make classroom more active and fun, LCD whiteboard can let student's / Kids' attraction focused on teaching and new knowledge.
Now the price of interactive monitors for business is affordable, if you have needs to buy a touch screen conference room monitor, please contact us.
As a lcd screen manufacturer, we can offer kinds of lcd screen for sale, if you are interested, please leave us a message.
