Anti Climbing High Security Fence

We supply and deliver Anti Climb Fence Panels, razor wire concertina

Non climb fencing panels are popularly made of 358 weld mesh structure. 358 anti climbing fence is extremely difficult to penetrate, with the small mesh aperture being effectively finger proof, and extremely difficult to cut through with conventional hand tools. '358' comes from its measurements 3" x 0.5" x 8 gauge, about 76.2mm x 12.7mm x 4mm in metric system.

High Security 358 Anti Climb Fence is the superior security fencing system when used with concertina wire coils and CCTV monitor system. Widely used for prison, airmport, sea port and various border security protection.

General Information of Supply :
Common wire thickness: 4mm
Hole size :76.2*12.7mm, 12.5x75mm
General panel width: 2.2m, 2.4m, 3m
Panel height: 1.8m, 2.1m, 2.4m, 3m
Post height : 2m, 2.3m, 2.5m, 2.7m, 3m, 3.6m
Post type: square fence post 60*60*2.0/2.5,80*80*2.0/3.0mm
Fitting: Flat bar, metal clips
Material: Carbon steel
Surface treatment: Electric galvanized, hot dipped galvanized, then powder coated; hot dipped galvanized
Color: Green, black, biege, others

SUPPLY OF ANTI-CLIMBING FENCE， GREEN PVC POWDER COATED, GI WIRE

Technical Details

Mesh Panel:
Panel size: 3000 mm height x 2515 mm width.
Material: ASTM A 641. Wire shall be steel and have class 3 zinc coating as specified in ASTM A 641 unless otherwise specified, wire shall have a tensile strength not less than 58,000 pounds per square inch.
Mesh pattern: 76.2 mm (3") * 12.7 mm (0.5") resistance welded well at each intersection with 1 'V' shaped beam.
Wire diameter: 4 mm horizontal wire and vertical Wire.
Weld strength: range 540 to 690 N/m2.
Surface treatment: Steel mesh fence panels made from hot dipped gi wire, then PVC powder coating (Min. 100 micron), or PVC powder painting.
Life span: With an additional powder coating protection, the metal fence is expected to have an increased potential life span to 25 years.
Color: Green RAL 6005

Fence posts:
Material: ASTM A 702 high grade steel tor maximum strength / rigidity. Steel fence posts and braces shall be made of high-grade steel for maximum strength and rigidity conforming to the requirements of ASTM A 702 far steel fence posts.
Post Section. 80 * 80 mm.
Post Plate thickness: 2.5 mm
Post Length: 3800 mm.
Base Plate: 10 mm Plate: 200 x 200 mm
Fimsh: inside and outside galvanized ( Min. 275 g/m2), subsequently covered with a polymer powder (Min. 60 micron).
Color: Green RAL 6005.
Post cap: metal caps
Metal clips and clamps are to be hot dip galvanized then powder coating in green color RAL 6005.

Material and fixing clamps: Interior / straight section
Material: ASTM A 702 - mm 80 * 80 * 2.5 SHS Clamps
Material mm 80 x 80 x 2.5 SHS Clamps NO. 10 {per straight section)
Made of high-grade steel for maximum strength and rigidity conforming to the requirements of ASTM A 702 for steel fence posts
Finish: inside and outside galvanized (Min . 275 g/m2), subsequently covered with a polymer powder (Min. 60 micron).
Metal clips and clamps are to be hot dip galvanized then powder coating in green color RAL 6005.

Material and fixing clamps: Exterior/corner section
ASTM A 702 - mm 80 * 80 * 2.5 SHS Clamps
Material mm 80 x 80 x 2.5 SHS Clamps No. 20 (per corner section)
Made of high-grade steel for maximum strength and rigidity conforming to the requirements of ASTM A 702 for steel fence posts
Finish: inside and outside galvanized (Min 275 g/m2), subsequently covered with a polymer powder (Min. 60 micron)
Metal clips and clamps are to be hot dip galvanized then powder coating in green color RAL 6005.

Inspection
All raw materials shall be tested.
All items listed shall be inspected at each stage of manufacture. A sample ot each manufacturing batch shall be made available tor inspector to determine it the required quality level as detailed has been met. The result of the inspection shall determine the acceptance or otherwise of the whole batch.
