Jiaxing Fuying Composite Materials is China Conventional Double Glass Solar Module manufacturer
Product Features:
1. Half-cell battery technology, brand new circuit design.
2. Superframe, can bear 5400Pa mechanical load test.
3. Drainage system design to prevent deformation and cracking of the frame due to freezing.
4.Significantly reduce the risk of hot spots and reduce power loss.
5.Excellent anti-PID performance and strict quality control ensure the high reliability of the produc
Category | model | FY166M440-72 | |
72 version (9BB-166) | Standard test conditions:AM1.5,E=1000W/m2,TC=25℃ | ||
Pmax | 275W~450W | Maximum system voltage | 1500V |
Tolerance range | 0~5W | Maximum system current | 20A |
Vpm | 41.2V | Operating temperature | -40~85℃ |
Ipm | 10.7A | Cell type | Monocrystalline silicon |
Voc | 49.3V | Weight (Kg) | 25.2kg |
Isc | 11.2A | Specification (mm) | 2089*1033*5.3 |
Max power:280w Size and No of cell:60pcs/156*156 Voltage at max.power(Vmp):31.70 Current at max.power(Imp):8.84 Open circuit voltage(Voc):38.40 Short circuit current(Isc):9.44 Size:1658*992*6mm Weight:23.5kg Maz.syst.oper.voltage:1000v Operate Temp.scope:-40/+85℃ Test ...
