Filter Press

Place Of Origin: china

Minimum Order: 1

Packaging: N/A

Delivery: 3 to 6 months

HVD-FP-A fully automatic filter press is composed of a filter plate or filter frame. The filter plate and the filter frame form a set of filter chambers in the middle of press filter machine. The surface of the filter plate is grooved and the protruding part is used to support the filter cloth. The filter frame or filter plate has a through-hole in the corner, which forms a complete channel after assembly, and can pass into the suspension, washing water, and lead out the filtrate. Plate and frame filter press machine working like this: each side of the filter plate or the filter frame has a handle supported on the beam, and the filter plate or the filter frame is pressed down by a pressing device. The filter cloth between the filter plate or between the filter plate and the filter frame acts as a sealing gasket. The suspension fluid is pumped into the filter chamber and formed on the filter cloth until the filter chamber is fully filled. The filtrate passes through the filter cloth and flows along the groove of the filter plate to the corner channel of the filter plate or plate frame for centralized discharge. After filtration, the filter residue can be washed with clean water. After washing, sometimes also through the compressed air, remove the remaining washing liquid. Then open the recessed plate filter press to remove the filter residue, clean the filter cloth, press the filter plate again, and start the next working cycle.

Features of Filter Press

The plate and filter press adopts the hydraulic device as the power device for pressing and loosening the filter plate;

The upper part of the main beam is covered with 304 stainless steel, which can effectively reduce the friction resistance between the filter plate and the main beam and reduce the working strength;

The integrated hydraulic control system of plate frame filter press adopts international famous brand components, hydraulic system valve body precision processing, to ensure durable;

Membrane plate filter press adopts new raw materials and formula, high-pressure molding, high strength, high working pres, high filtration efficiency, no blocking, no breaking plate, with high strength, lightweight, high temp. resistance, corrosion resistance, acid and alkali resistance, non-toxic, tasteless, and other characteristics.

Equipped with a variety of safety devices to ensure the safety of operators, simple operation, convenient maintenance.

Plate and filter press equipped with PLC control, automatic plate shifting, automatic unloading, automatic drip tray, diaphragm pressing, open flow or dark flow, washing/blowing mode, high temp. resistance of filter board, etc.

HongVadar relies on professional design, strict production management, the fine processing procedure, provides high efficiency and energy-saving fully automatic filter press for sale with prefercienal filter press machine price. As the filter press machine manufacturers, HongVadar has passed the international ISO9001 quality system certification, and with the design and manufacturing capacity of pressure vessels. Customers can choose international ISO, EU CE, and other standards for equipment design and production according to their needs.

Technical Parameter (Hydraulic Chamber Filter Press)

Model Filtering area, m2 Chamber qty. Cake thickness, mm Chamber volume, m3 Filtration pres. MPa Power, kW Overall dimension

mm Weight, kg

HVD-FP450-A10 10 26 25 0.126 0.5-1.6 1.5 2700*700*800 1210

HVD-FP630-A20 20 26 30 0.297 2.2 3360*960*1060 2520

HVD-FP800-A40 40 40 30 0.605 2.2 4720*1230*1160 3350

HVD-FP800-A60 60 60 30 0.907 2.2 5940*1230*1160 4040

HVD-FP1000-A80 80 50 30 1.19 2.2 6180*1460*1360 5640

HVD-FP1000-A100 100 62 30 1.48 2.2 6910*1460*1360 6200

HVD-FP1250-A150 150 58 40 3.02 4 7590*1770*1620 10640

HVD-FP1250-A200 200 77 40 4.02 4 8940*1770*1620 12040

HVD-FP1500-A300 300 77 40 5.96 5.5 10820*2150*1880 26850

HVD-FP1600-A400 400 92 35 6.98 5.5 11620*2250*1980 28750

HVD-FP1600-A500 500 115 35 8.74 5.5 13370*2250*1980 32970

Beijing Hongvadar Engineering Technology Co. Is a professional sweet corn processing plant, we provide single cyclone separator, diagram of plate and frame filter press and etc. Want to know more, contact us.
