Twill Weave Wire Mesh
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Weaving Method: Twill weave is applied for weaving of heavy meshes and thicker wire fabric with square opening compared with Plain Weave
Features: Twill woven wire mesh has square aperture, it is less rigid than plain weave, easy deforming. It is a strong wire cloth due to ratio of wire diameter and aperture, mostly used for filtration between 25 to 130 μm .
Supplying Forms: Processed into discs, packs, filter baskets or other elements for various industrial uses.
Specification of Twill Woven Wire Mesh in Stainless Steel:
| Mesh Count Warp x Weft | Wire Dia mm | Wire Dia inch | Aperture mm | Aperture inch | Micron Rating |
| 100 x 100 | 0.1250 | 0.0049 | 0.1295 | 0.0051 | 130 |
| 120 x 120 | 0.0939 | 0.0037 | 0.1168 | 0.0046 | 117 |
| 165 x 165 | 0.0482 | 0.0019 | 0.1041 | 0.0041 | 104 |
| 200 x 200 | 0.0584 | 0.0023 | 0.0685 | 0.0027 | 68 |
| 250 x 250 | 0.0533 | 0.0021 | 0.0482 | 0.0019 | 48 |
| 300 x 300 | 0.0355 | 0.0014 | 0.0482 | 0.0019 | 48 |
| 300 x 300 | 0.0400 | 0.0016 | 0.0431 | 0.0017 | 45 |
| 325 x 325 | 0.0355 | 0.0014 | 0.0406 | 0.0016 | 41 |
| 350 x 350 | 0.0304 | 0.0012 | 0.0431 | 0.0017 | 43 |
| 400 x 400 | 0.0304 | 0.0012 | 0.0330 | 0.0013 | 33 |
| 500 x 500 | 0.0254 | 0.0010 | 0.0253 | 0.0010 | 25 |
- Country: China (Mainland)
- Business Type: 制造商
- Market:Africa,Americas,Asia,Emerging Markets,Europe,European Union,G20,Middle East,Oceania
- Founded Year:2000
- Address:No.156 Industrial Park,Dezhou,China
- Contact:Lu Feng
