Model | SP-IN4 |
Motor power | 7.5KW |
Reducer | 350 type |
Feed material | iron pipe |
Feeding round tube diameter | 1.5 inch (cun) |
Forming Roller | 8 forming + 2 straightening |
Working speed | 10 meters / minute |
Roller material | GCr15 heat treatment after finishing |
Spindle material | 40Cr after quenching and tempering |
Transmission mode | 1.2 inch chain sprocket drive |
