Galvanized Cast Iron Trailer Hydraulic Disc Brake Caliper

The galvanized trailer hydraulic disc brake caliper is made from cast iron, has a phenolic piston and two pieces of non-asbestos semi-metal brake pads. Having excellent anti-rust, anti-corrosion, and anti-wear performance. This trailer hydraulic disc brakes fit the hubs / rotors which have 5 x 4.25” PCD, 5x 4.5” PCD, 5 x 4.75” PCD or 6 x 139.7mm PCD, they suitable for installations where more than one axle is used. This trailer hydraulic brake caliper applies to boat trailers, caravans, car trailers and box trailers. The hydraulic brake caliper is easy to install, it can replace the AL-KO hydraulic calipers.

Features

lUsed with IQ7 or hydraulic over ride couplings (the load weights exceeding 2000 kg).

lRequirement of disc hubs and rotors: Thicknesses from 12 mm to 15 mm.

lGalvanized coated can prevent the corrosion of seawater.

lMounting bolts, spring washers and pads are included. Quick and easy installation.

lThis hydraulic disc brake calipers exchange with AL-KO and Trojan MK7 calipers, but have different appearance.

Specifications

ØAxle Capability: 1400 kg (15”/16” wheel), 1600 kg (13”/14” wheel)

ØMounting Bolts: 12mm H.T. x 45mm

ØBolt Spacings: 88.9mm (3.5”)

ØRecommended operating pressure: 6.9 mpa (1000psi)

Product Composition

²Non-asbestos semi-metal brake pads x 2

²Galvanized Cast Iron Brake Caliper Body x 1

²Bleed Screw x 1

²Phenolic Resin Piston x 1

²Piston Seal x 1

²Piston Dust Boot x 1

²Slide Pin Kit x 1

²Slide Dust Boot x 2
