CCTV Surge Protective Device
Product sourcing details
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Brand: PROMOV / TAIHANG or Equivalent
Type: Type 3 (Protection in accordance to EN61643-11)
Model: TD2-06 / TD2-14 / TD2-15
Max Continuos Voltage, Uc: 220VAC / 36VDC / 24VDC / 12VDC
Discharge Current, In / Imax: Power Line: 10/20KA ; Video Line: 5/10KA ; Control Signal: 5/10KA
Insertion Loss: < 0.4 dB
Response Time, Ta: Power Line: 25ns ; Video line: 2ns ; Control Signal: 2ns
Temperature, Tu: -25 to 80 Deg C
Enclosure Material: Aluminium Alloy
Connector Type: Power Line: Screw ; Video Line: BNC ; Control Signal: Screw
Type: Type 3 (Protection in accordance to EN61643-11)
Model: TD2-06 / TD2-14 / TD2-15
Max Continuos Voltage, Uc: 220VAC / 36VDC / 24VDC / 12VDC
Discharge Current, In / Imax: Power Line: 10/20KA ; Video Line: 5/10KA ; Control Signal: 5/10KA
Insertion Loss: < 0.4 dB
Response Time, Ta: Power Line: 25ns ; Video line: 2ns ; Control Signal: 2ns
Temperature, Tu: -25 to 80 Deg C
Enclosure Material: Aluminium Alloy
Connector Type: Power Line: Screw ; Video Line: BNC ; Control Signal: Screw
- Country: Malaysia
- Business Type: Distributor/Wholesaler
- Market: Asia,Europe,Emerging Markets,Americas
- Founded Year: 2010
- Contact: Justin Ng
