Aluminum Base LED Bulb PCB
Product Quick Detail
- Place Of Origin
- China (Mainland)
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- N/A
Specifications
Material: Aluminum 2.8 W/m.k
Finished Thickness: 1.6mm
Outer Copper:/ 2 OZ
Surface treatment: HASL LF
Min Line Width: ≥ 0.3mm
Min Line Space: ≥0.30mm
Min Hole: ≥1 mm
Solder Mask: White X 1 side
Silkscreen: Black X 1 side
Application: LED Light
- Country: China (Mainland)
- Business Type:
- Market:Americas,Europe,Asia,European Union
- Founded Year:1999
- Address:
- Contact:Lucina Lu
