Illumination geometry | 45/0 (45°annular illumination, 0° viewing angle) |
Illumination light source | Full spectrum LED light source |
Measuring aperture | 8mm |
Measurement conditions | Light source D65, field of view 10° |
Measuring time | about 1s |
Color space | CIE Lab, Luv, LCh, Yxy, CMYK, RGB, Hex |
Color difference formula | ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00 |
Repeatability | Standard deviation ΔE*ab is within 0.03 (average value of 30 measurements on whiteboard every 3s after calibration) |
Dimension | 31.7×31.7×70.4mm (L*W*H) |
Weight | about 51g |
Power supply | Rechargeable lithium battery 3.7V@700mAh, can continuously measure 10,000 times under full power |
Data transmission | Bluetooth |
Charging port | USB (Type-C) |
Operating temperature | 0~45℃, 0~85%RH (no condensation) |
Storing temperature | -25~55℃, 0~85%RH (no condensation) |
The Portable CCD LED Colorimeter Spectroradiometer has the following versions which can measure different parameters: LISUN Model Function Wave Range LMS-6000 illuminance (lux), E(Fc), Ee(W/m2), Tc (K), Duv Correlated Color Temperature (CCT), Chromaticity Coordinates, CRI, ...
The Portable CCD LED Colorimeter Spectroradiometer has the following versions which can measure different parameters: LISUN Model Function Wave Range LMS-6000 illuminance (lux), E(Fc), Ee(W/m2), Tc (K), Duv Correlated Color Temperature (CCT), Chromaticity Coordinates, CRI, ...
Illumination geometry 45/0 (45°annular illumination, 0° viewing angle) Illumination light source Full spectrum LED light source Measuring aperture 8mm Measurement conditions Light source D65, field of view 10° Measuring time about 1s Color space CIE Lab, Luv, LCh, Yxy, ...
Illumination geometry 45/0 (45°annular illumination, 0° viewing angle) Illumination light source Full spectrum LED light source Measuring aperture 8mm Measurement conditions Light source D65, field of view 10° Measuring time about 1s Color space CIE Lab, Luv, LCh, Yxy, CMYK, ...
LS170 portable App smart colorimeter is meant to supply users color measurement and stable color comparisons for materials and products wherever color control is vital . Linshang LS170 colorimeter is an exquisite and portable color difference measurement tool, this portable ...
Linshang portable colorimeter is used to provide best color measurement and color comparisons with color quality control App. This portable colorimeter use d/8 measuring principle. It is widely used in industries such as plastics, leather, etc If you want to collect the color ...
LS171 colorimeter is a new instrument to provide color measurement and stable color comparisons for materials and products wherever color control is important. The instrument complies with relevant international CIE standards and GB standards. It adopts D/8 optical structure and ...
Whether it\'s small FPD, LCD, mobile phone display or large panel displays, such as TV. It is necessary to detect the optical performance parameters such as luminance, chromaticity, flicker and uniformity of the product in production process. Adjusting these optical parameters ...
Imaging Luminancemeter meets the various measurement needs of FPD, backlit keyboards, and LED lighting.RayClouds Advantages of Imaging Luminancemeter Multiple exposure and ND filters to achieve a wide range of measurement and up to 1000000:1 contrast. The XYZ filter and ...
