Beacon light for heliport new model
Product Quick Detail
- FOB Price
- USD $546.00 / Piece
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- 549
- Delivery
- 15 Days
Specifications
GS-HP/B Heliport beacon light, its base is caste by high intensity aviation aluminum with full sealed structure.
Light source adapts high efficient CREE chip and cooperate with condensing lens that owned independent research and developing patent, service life can up to 20yeras, offer high light intensity, long service life and other characteristics.
Lamp shade adopts PC, which has strong ability of corrosion, anti-UV, anti-shock.
Controlling circuit has strong ability of lighting protection and with anti-surge protection device, it can adapt to extremely bad working environment.
This light can emitted white color signal at night or dim day, indicate the location of helipad clearly
| Name | Parameter |
| Model | GS-HP/B |
| Power voltage | Optional voltage: AC180V~264V |
| Power Supply Frequency | 50HZ～60HZ |
| Power Consumption | ≤20W |
| Working mode | Flashing 4times/2S |
| Optional Emitting Light Colors | White |
| Service Life of the Light Source | ≥10years |
| Overall Size(mm) | 255 x 255 x 210(mm) |
| Installation size | 234mm x M8 |
| IP Protection | IP67 |
| Ambient Temperature | -55℃～85℃ |
| Net Weight | 3.8KG |
| Anti-Wind Ability | 80m/s |
Dongguan Xinan Technology Co.,Ltd. is a high technology enterprise engaging in research, production, sales and after sale services for a wide range of Aviation Obstruction Light, LED Warning Light, Heliport Light, LED Marine Lanterns, Solar Garden/Street Light. We are a domestic market leader in the field of navigation lights and a supporter of green and safe emissions. Our products are widely used in domestic and overseas market in many fields,eg.Civil Airports, Helipads, Communication Towers, Factory, Power Plant Chimneys, Television Tower, Port, Bridges, and High-rise buildings, Buoy in sea, etc.
All our products are designed and manufactured strictly according to ICAO (International Civil Aviation Organization), FAA (Federal Aviation Administration) and IALA(International Association of Lighthouse Authorities). we are proud to have served customers from all across the world.
Contact person
Ms kary
qq;926365176
- Country: China (Mainland)
- Business Type: Solar marine light, Aviation obstruction light, Heliport light
- Market:South America,Middle East
- Founded Year:2019
- Address:santun Houjie
- Contact:kary guo
