Gabion Basket
Gabion basket is a kind of hexagonal wire mesh that is made of steel wires. The size of wire is according to the different sizes of hexagonal net. For steel wire, The sizes from 2.0mm To 4.0mm can be adopted, and for PVC coated wire, The size from 3.0 To 4.5mm, will be used as a mesh wire, and the lacing wire is generally heavier than the mesh wire.
Material:low carbon iron wireQ195
Wire Gauge:2.0mm--5.0mm
Hole Size:60*80,80*100,100*120,120*150
Mesh Size:2*1*1m,3*1*1m,2*1*0.5m,3*1*0.3m or as customer requirement
Surface Treatment:electro galvanized,hot dipped galvanized
Application:rock fall protection,gabion wall,gabion matresses,roadway protection.
Features:
Economic. Just fill the stone into the gabions and seal it.
Simple installation. No special technology needed.
Weather proof under natural destroy, corrosion resistant.
No collapse even under big scope of deforming.
Sludge in the stones is good for plant growing. Mixed to form a integrity with the natural environment.
Good permeation can prevent the damage by hydrostatic.
Less transport freight. It can be folded together for transport and further installation.
Specification:
Nominal Box sizes (m) |
Mesh size (mm) |
No. of diaphragms (no.) |
Capacity per box (m³) |
1.0x1.0x0.5 |
50x50 75x75 50x100 100x100 |
0 | 0.50 |
1.0x1.0x1.0 | 0 | 1.00 | |
1.5x1.0x0.5 | 0 | 0.75 | |
1.5x1.0x1.0 | 0 | 1.50 | |
2.0x1.0x0.5 | 1 | 1.00 | |
2.0x1.0x1.0 | 1 | 2.00 | |
3.0x1.0x0.5 | 2 | 1.50 | |
3.0x1.0x1.0 | 2 | 3.00 | |
4.0x1.0x0.5 | 3 | 2.00 | |
4.0x1.0x1.0 | 3 | 4.00 |
