Superda High Quality Electrical Enclosure Roll Forming Machine

Place Of Origin
China
FOB Price
69000
Minimum Order
1
Packaging
Container
Delivery
65 Days

Automatic Galvanized Steel & Stainless SteelEnclosure Box Production Line

Product specifications: height adjustable 300-1200mm, depth adjustable 160-400mm.

Technical parameters

Item Technology parameter
Material Material cold-roll strip,galvanized steel strip
Thickness 1.0-1.5mm(base on 1.5mm design, when T.1mm effect alittle not good as 1.5mm)
Coil Inner Ф360—Ф510
Process Form Speed 0-13m/min
Length Not limit
Quality Length Precision L≤1000mm:±0.5㎜
Straight,

Deflection

L≤1000mm,Bend no more than 1mm;Deflection no more than 2mm
Forming size As per design

Steel Enclosure Box MakingProcess

Uncoiler→ Straightening→Servo feeder→Hydraulic device
