1.Annual output:
5million to 30 million sqm(based on thickness of 9.5mm gypsum
board)
2.Working time: 24hours/day and 300 working
days/year
3.Raw material: Gypsum powder, shielding paper, modified starch, foaming agent,
glue
4.Fuel: Natural gas, diesel, heavy oil or
coal
5.Product quality and specification:
1) The product is in compliance with National
Standard GB/T9775-2008
2) Product specification:
Length: 2400mm~3600mm
Width: 1200mm or
1220mm
Thickness: 8mm-20mm
6.Main process:
1)Raw material
blending;
2)Shaping;
3)Wet board/panel conveying;
4)Drying;
5)Dry board/panel
conveying;
6)Finished product stacking and storage.
7.Main technology:
The production line adopts special designed hot air stove heating
system
8.Raw material consumption list:
(Based on 9.5 mm gypsum board for reference)
Gypsum | 6.8kg/m2 |
Shielding paper | 0.48kg/m2 |
Modified starch | 0.035kg/m2 |
Foaming agent | 0.008kg/m2 |
Glue | 0.005kg/m2 |
Fiberglass (optional) |
0.025kg/m2 |
Electricity | 0.3kwh/m2 |
Water | 4.8kg/m2 |
Light oil | 1,000,000kcal/hour |
Natural gas | 0.45m³/m2 |
Till now, we've manufactured and supplied complete sets of machine lines to Russia, Oman, Uzbekistan,United Arab Emirates, Iran.
