Electrical cabinet frame 16 fold roll forming machine
Product Quick Detail
- 60000
- 90000
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- Container
- Delivery
- 65 Days
Specifications
Automaitc electric factory using cabinet frame roll forming machine with welding for electric cabinet rack, electronic box pole, metal case frame which using in switchgear system, low voltage panel building, control cabinetelectrical instruments etc.
Cabinet frame roll forming machine
Equipment for producing electric cabinet frame
Technical parameters
| No. | ITEM | PARAMETER | REMARK | |
| 1 | MATERIAL | Type | Cold-rolled strip steel, galvanized sheet | |
| T.(mm) | 1.5mm | | ||
| Yield Strength (Mpa) | Q235 | | ||
| 2 | Forming product Width | 42.5mm | | |
| 3 | Forming speed (m/min) | 2-6m | Including welding | |
| 4 | Forming main power (KW) | 11 KW*2 pcs | FYR | |
| 5 | Hydraulic power (KW) | 18.5 KW | FYR | |
| 6 | Voltage | AC380V，50Hz，3P | |
Electronic control panel frame production line process
2 in 1 Uncoiler Straightening→servo feeder→punch → Guide device → roll forming machine → Roller welding →shear device (including knife)→ finished product rack
- Country: China (Mainland)
- Business Type: Fire hose reel cabinet roll forming machine, Distribution box roll forming machine, filter frame roll forming machine, oval tube forming machine, square tube roll forming machine, triangular tube machine, electronic cabinet roll forming machine
- Market:Asia,European Union
- Founded Year:2009
- Address:No.95, Ainan Rd, Longdong district, Longgang area
- Contact:Demi Wu
