Superda Machine Electrical Junction Box Meter Enclosure Fabrication Equipment
Product Quick Detail
- 30000
- 68000
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- Container
- Delivery
- 45 Days
Specifications
Meter Enclosure Roller Technology Paratmer (Panel width adjustable)
5.1 Forming Roller：16 stations，and add Rub-roll, To make sure the surface profile no scratches.
5.2 Side Panel：T.18mm ,A3 steel Heavy duty 。
5.3 Rolling speeding: 6-12 m/min。
5.4 Roller material：GCr15，overall quenching, hardness HRC56-62 ℃.
5.5 Motor power：7.5KW。
5.6 Main Roller ：dia.75mm，45 #。
5.7 Equipment base: 45 # H type using welded steel plate.
5.8 Transmission: chain drive.
5.9 Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead
to injury transmission section covered with protective cover, to ensure the safety of workers.
Shenzhen Superda Machine CO., Ltd Devices completed electric meter box prodution line
https://www.superdamc.com/cabinet-box-forming-machine
| No. | Machine name | QTY | REMARK |
| 1 | Uncoiler, straightener | 1 |
|
| 2 | Servo Feeder | 1 |
|
| 3 | Hydraulic station | 2 |
|
| 4 | Guide device | 1 |
|
| 5 | Forming machine | 1 |
|
| 6 | Hydraulic machine | 1 | With mould (2/3 sets) |
| 7 | Follow Shear | 1 | Including knife |
| 8 | Collect rack | 1 |
|
| 9 | Control system | 2 |
|
| 10 | Box bending device | 1 | With mould |
- Country: China (Mainland)
- Business Type: Fire hose reel cabinet roll forming machine, Distribution box roll forming machine, filter frame roll forming machine, oval tube forming machine, square tube roll forming machine, triangular tube machine, electronic cabinet roll forming machine
- Market:Asia,European Union
- Founded Year:2009
- Address:No.95, Ainan Rd, Longdong district, Longgang area
- Contact:Demi Wu
