Items Capability
1 PCB assembly min IC pitch 0.30mm (12mil)
2 PCB assembly foot pin SO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA
3 PCB assembly min chip placement 01005
4 PCB Assembly Max PCB Size 410 x 600mm (16.2 x 23.6″)
5 PCB assembly min PCB thickness 0.35mm (13.8mil)
6 PCB assembly maximum BGA size 74 x 74mm (2.9 x 2.9″)
7 PCB assembly BGA ball pitch 1-3mm (4-12mil)
8 PCB assembly BGA ball diameter 0.4-1mm (16-40mil)
9 PCB assembly QFP lead pitch 0.38-2.54mm (15-100mil)
10 PCB assembly packing Anti-static bubble bag and cartol
For PCBA order, provide us:
1. PCB Gerber file
2. BOM list for PCBA
3. Sample of PCB and PCBA
4. Test method for PCBA
