340w monocrystalline solar module for solar power station
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Size and No of cell:72pcs/156*156
Voltage at max.power(Vmp):38.47
Current at max.power(Imp):8.84
Open circuit voltage(Voc):45.29
Short circuit current(Isc):9.27
Size:1950*992*40mm
Weight:23kg
Maz.syst.oper.voltage:1000v
Operate Temp.scope:-40/+85℃
Zhejiang Macro-Solar Technology Co., Ltd isone of the most potential energy companies in China, integrating R&D, manufacture and sales of mono- and poly-crystalline photovoltaic modules, PVpowersystem and PV applications.
Since company established in 2006, Macro-Solarhas been offering the world with reliable renewable products which are internationally certified with, TUV,CQC,CE, IEC, ISO9001,ISO14001,OHSAS18001 and RoHS, etc. Currently,Ourannual production capacity is200MW for both mono and poly solar panels..
