Torched-on Bitumen Waterproof Membrane
Product Quick Detail
- 1
- 6
- Packaging
- Wraped with PE Film
- Delivery
- 15 - 20 workdays
Specifications
BITUFLAT™ membrane is a kind of torched-on, flexible, bituminous waterproofing sheet based on premium modified plastomer or elastomer bitumen, reinforced with non-woven polyester or composite glass-fiber mesh in the middle,bottom&surface coated with PE film.
· Good waterproof performance
· Anti-corrosion, mildew resistant and weather resistant
· High tensile and tearing strength, elongation and size stability which accommodates substrate movement and deformation
· Hot melt construction, solid and long-lasting
· Anti-puncture and rooting resistant, fatigue resistant
3. Technical Data
| No. | Item | I | II | ||||
| PY | G | PY | G | PYG | |||
| 1 | Soluble content/(g/m2)≥ | 3mm | 2100 |
|
|||
| 4mm | 2900 |
|
|||||
| 5mm | 3500 | ||||||
| Test |
|
No flame |
|
No flame |
|
||
| 2 | Heat resistance | ºC | 90 | 105 | |||
| ≤mm | 2 | ||||||
| Test | No flow, no dripping | ||||||
| 3 | Low temperature flexibility/ºC | -20 | -25 | ||||
| No crack | |||||||
| 4 | Impermeability 30minutes | 0.3MPa | 0.2MPa | 0.3MPa | |||
| 5 | Tension | Maximum/(N/50mm) | 500 | 350 | 800 | 500 | 900 |
| Secondly-Maximum |
|
|
|
|
800 | ||
| Test | No crack, no apart | ||||||
| 6 | Elongation | Maximum/%≥ | 30 |
|
40 |
|
|
| Secondly-Maximum≥ |
|
|
15 | ||||
| 7 | Oil Leaking | Pieces≤ | 2 |
4.Application
· Roof and underground in industrial and civil buildings
·Bridge, subway, tunnel, swimming pool, etc
· Waste landfill, sewage plant, irrigation system, etc
