Welcome to visit our showroom! It's my honor to introduce you our product.
Please check the below inside picture of this model:
Features:
1, Outstanding Arc Stability with Low Spatter.
2, Auto Protection against Over-Voltage and Over-Current.
3, Wide Range for Input Voltage: 415V ± 15%.
4, Super Portable and Energy Saving.
Applications:
Education
Maintenance, Repair
Farm
Fabrication
Construction
Steel Erection
Specification:
Parameter/Model | ARC200(IGBT) |
Input Voltage | AC220V±15% |
Frequency | 50/60 |
Rated Input Current | 27.6 |
No-load Voltage | 59 |
Output Current Range | 40-200 |
Rated Output Voltage | 36 |
Duty Cycle | 60 |
No-load Loss | 80 |
Efficiency | 85 |
Power Factor | 0.93 |
Insulation Grade | F |
Housing Protection Grade | IP21 |
Net Weight | 26.5 |
Dimension | 565*306*432 |
Additional Accessories |
Earth clamp with 3M cable(35mm2 500A) Electrode holder with 3M cable (35mm2 500A) |
