1. Introduction
Welded pipe production technology is simple, high production efficiency, varieties and specifications, equipment investment is less. The strength of spiral welded pipe is generally higher than that of longitudinal welded pipe. The welded pipe with larger diameter can be produced with narrower billet, and the welded pipe with different diameters can be produced with the same width of billet. The general strength is lower than seamless titanium pipe.
2. Materials & standards
Materials | Grade 1, Grade 2, Grade 5, Grade 7, Grade 9, Grade 12 | |
Standard | Alloy titanium | Gr.1,Gr.2 |
ASTM B861, ASTM B862, ASTM B337, ASTM B338 and ASTM 4942 |
Gr.5(Ti-6Al4V),Gr.7(Ti-0.2Pd),
Gr.9(Ti-3Al2.5V),Gr.12(Ti-0.3Mo-0.8Ni) |
|
Technique | Hot forging, hot rolled, cold rolled | |
States | Annealed (M) | |
Shape | Round, square, coiling | |
Surface | Pickling or Bright |
3. Characters
Low Modulus of Elasticity
Good thermal properties
Nonmagnetic and Non-toxic
Excellent Bearing to cryogenic property
Good resistance to effect of heat
Excellent Corrosion Resistance
Low Density and High Strength
4. Physical Properties
Grade | State | Tensile strength(min) | Yeild strength (min) | Elongation (%) | ||
Ksi | MPa | ksi | MPa | |||
GR 1 | (M)Annealed | 35 | 240 | 20 | 138 | 24 |
GR 2 | (M)Annealed | 50 | 345 | 40 | 275 | 20 |
GR 5 | (M)Annealed | 130 | 895 | 120 | 828 | 10 |
GR 7 | (M)Annealed | 50 | 345 | 40 | 275 | 20 |
GR 9 | (M)Annealed | 90 | 620 | 70 | 438 | 15 |
GR 12 | (M)Annealed | 70 | 438 | 50 | 345 | 18 |
5. Production specifications
Types |
OD (Outside Diameter)
(mm) |
Wall Thickness
(mm) |
Length
(mm) |
Welded Tubes | 19.0-630.0 | 0.5-10.0 | 1000~15000mm |
Note: Non-standard sizes are also available.
6. Delivery
We can deliver the Titanium products according to the stock status, usually 3-25 days.
7. Packing Details
Packed with wooden case, cardboard case or according to the requirements of customers
