| Uses: | | | | | | | | |
| 1.Whether you are laying turf around a golf course or growing small crops,the rotary hoe |
| is perfect for preparing your top soil for planting | | | | |
| 2.Create a smooth finish and is perfect for crop and lawn preparation | | |
| 3.Improving productivity,as well as presentation | | | | |
| | | | | | | | |
| Features: | | | | | | | | |
| 1.Adjustable rear flap for safety as well as providing a smooth finish | | |
| 2.Height adjustable skids for depth control | | | | | |
| 3.Extra strong design for long lift and reliability | | | | |
| | | | | | | | |
| Spectification: | | | | | | | |
| Model | IGQN-120 | IGQN-125 | IGQN-140 | IGQN-150 | IGQN-160 | IGQN-180 | IGQN-200 |
| Matched Power(hp) | 15-18 | 18-20 | 20-25 | 25-30 | 30-40 | 40-55 | 55-75 |
| Working Width(cm) | 120 | 125 | 140 | 150 | 160 | 180 | 200 |
| Knife Quantity | 26 | 26 | 30 | 34 | 38 | 50 | 54 |
| Type of Knife | IT225 | IT245 | IT260 |
| Net Weight(kg) | 215 | 220 | 230 | 240 | 251 | 415 | 430 |
| Overall Dimension(mm) | Lenth | 900 | 900 | 900 | 900 | 900 | 1020 | 1020 |
| Width | 1350 | 1450 | 1600 | 1740 | 1880 | 2056 | 2396 |
| Height | 1000 | 1000 | 1000 | 1000 | 1000 | 1152 | 1152 |
| Working Depth(cm) | Dry field | 8--14 | 12--18 | 12--16 |
| Muddy field | 10--16 | 14--20 | 14--18 |
| PTO speed(r/min) | 540 |
| Speed of Kinfe bar | 180-250 |
| Walking speed(km/h) | 1--4 | 2--5 |
| Rate of working depth(%) | >85 |
| Soil level after worked(cm) | <5 |
| vegetation covered rate(%) | >55 |
| the rate of crushed soil(%) | >50 |
| Linkage | Three tri-point suspension linkage |
