Details
Stainless steel welded wire meshis strong and long lasting. By it's very nature stainless steel wire needs no additional finish,such as galvanizing or PVC,to protect it.The wire itself is
extremely resistant to rust,corrosion and harsh chemicals. If you need a welded mesh or fence in an area with prolonged exposure to corrosives, stainless steel products will meet the demands.
The following specifications are most commonly available. Heavier gauges and other mesh sizes can be made to order. There may be minimum quantity or set-up charges required.
Material:SS201, SS202, SS302, SS304, SS304L, SS316, SS316L etc.
Weaving and Characteristics:We can also produce ultra-long and ultra-width etc.special standard welded wire mesh,the width can reach to 2.1m,the biggest wire diameter is 5.0mm,the
products is fit for the top quality fence netting,supermarket product frame,decorated inside and outside,food basket,advanced for animal cultivation. It has the merit of the intensity is high,no
rust,anti-corrosion acid-resisting,alkali-resisting and anti-high temperature etc.
Specification
Specification List of Welded Wire Mesh: | ||
Opening | Wire Diameter | |
In inch | In metric unit(mm) | |
1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
1" x 2" | 25.4mm x 50.8mm | 14,15,16 |
2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
Technical Note: 1.Standard roll length: 30m;width: 0.5m to 1.8m 2.Special sizes available at request 3.Packing: in waterproof paper in rolls. Custom packing available at request. |
