sucker rod guide /wheeled centralizers 7/8
Product Quick Detail
- FOB Price
- USD $50.00 / Piece
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- in wooden box
- Delivery
- 15 Days
Specifications
wheeled centralizers 7/8
sucker rod guide /wheeled centralizers 7/8
Wheel Centralizer While working, rely on the wheel to scroll in the tubing to prevent friction between the sucker rod and tubing.
Parameters:
| Type | Main Size | Rated Load (KN) |
Fit for
Tubing ID (mm) |
Working
Temperature (℃) |
Body Fatigue Life Time | |||||
|
Body OD
(mm) |
Roller
Thickness (mm) |
Roller
Section (mm) |
Max OD
(mm) |
|||||||
|
Basic
Size |
Limit
deviation |
Axial
Tension |
Radial
Extrusion |
|||||||
| LK46-5/8in | 32 | 5 | 60 | 46 | ±0.4 | 30 | 0.4 | 50 | ≤140 | ≥107 |
| LK46-3/4in | 38 | 7 | 50 | 0.7 | ||||||
| LK46-7/8in | 41 | 9 | 80 | 1.1 | ||||||
| LK58-5/8in | 32 | 7 | 75 | 58 | 50 | 0.7 | 62 | |||
| LK58-3/4in | 38 | 9 | 80 | 1.1 | ||||||
| LK58-7/8in | 42 | 11 | 100 | 1.4 | ||||||
| LK58-1in | 52 | 13 | 120 | 1.7 | ||||||
| LK46-3/4in | 38 | 9 | 90 | 72 | ±0.5 | 80 | 1.1 | 76 | ||
| LK72-7/8in | 42 | 11 | 100 | 1.4 | ||||||
| LK72-1in | 42 | 13 | 120 | 1.7 |
