Specifications:
Polycrystalline Diamond Compact(PDC), is manufactured with a diamond layer attached to a carbide substrate. Combining the properties of both super hardness and abrasion resistance of diamond with outstanding strength and toughness of of tungsten carbide, PDC has been widely used in mechanical industry, oil well drilling, geological prospecting drilling and coal mining.
Model | product no | angle (°) | diameter (mm) | thickness (mm) |
moreD30 | 360 | 30 | 1.6, 2.0, 3.2 | |
moreD42 | 360 | 42 | 1.6, 2.0, 3.2 | |
moreD48 | 360 | 48 | 1.6, 2.0, 3.2 | |
moreD51 | 360 | 51 | 1.6, 2.0, 3.2 | |
moreD58 | 360 | 58 | 1.6, 2.0, 3.2 | |
Note:The products can be manufactured per customer request as non-standard shapes such as rectangular, square, triangle, rhombus, sector and so on.
|
Application:
PCD Cutting tools: PCD cutting tools are mianly used for precessing aluminum and aluminum alloys (various silumin), copper and copper alloy, Babbitt metal, wood and various kinds of wood based fiber material,aluminum oxide reinforced floor boards, various kinds of wear-resistance plastic,bakelite, graphite,stone meterial, tungsten carbide, hard cartons,etc, where high abrasion resistance and good surface finish are required
Application Cases Of PCD cutting tool blanks
* 58mm diameter PCD wafers Have Sent To American Clients
Product name | PCD wafer, fine grade PCD |
size | 58 mm diameter, 2 mm thickness PCD blanks |
applicable workpiece | woodworking tools ( brazing the PCD to tool body then wire EDM again for final profile |
Advantages:
1.Longer tool life
2.Uniform surface finish
3.Reduced machine down time
4.High improved workpiece quality and excellent dimensional control
5.Increase productivity
6.High material removal rate
7.Low cost per piece
8.The tool life of a PCD cutting edge is usually 50 to 250 times greater than that obtained with conventional tungsten carbide cutting tools.
If you have any questions, please contact us
Whats App:+8618638297665
Skype:18638297665
Alisa@moresuperhard.com
Tel:18638297665
URL:www.moresuperhard.com
