Wireline BOP For oilfield drilling
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Double Ram BOP
Blowout Preventers are designed to give positive protection against blowouts when operating with wire line in well services work, by providing a positive seal around wire line.
This BOP's are available basically in two types: Hydraulically Operated and Manually Operated, with configurations as desired. An equalizer valve allows the operator to equalize the pressure with
lubricator pressure.
Blowout Preventers are available in sizes ranging from 2-1/2" ID through 6-3/8" ID and 3000 PSI through 15,000 PSI working pressure. Contact factory for details on pump, fittings, hoses and other
accessories.
Technical Specification:
| 1 | Nominal Bore | 2 1/2"- 6 3/8" |
| 2 | Working Pressure | 3000 PSI – 15000 PSI |
| 3 | Working Temperature | Class LU (-46°C~121°C) |
| 4 | Working Medium | Oil, Natural gas, mud and gas containing H2S, CO2 |
| 5 | Material Class | AA, BB, CC, DD, EE, FF, HH |
| 6 | Performance Requirement | PR1 – PR2 |
| 7 | Specification Level | SPL1 – PSL4 |
| 8 | Port | Shanghai |
| 9 | Delivery Date |
About 7- 25 days |
