CHEMICAL COMPOSITION
Specification | Low chromium | Medium chromium | High chromium | ||||||
Al2O3
(%) |
Cr2O3
(%) |
Na2O
(%) |
Al2O3
(%) |
Cr2O3
(%) |
Na2O
(%) |
Al2O3
(%) |
Cr2O3
(%) |
Na2O
(%) |
|
F12-F80 | ≥98.50 | 0.20-0.45 | ≤0.50 | ≥98.20 | 0.45-1.00 | ≤0.55 | ≥97.40 | 1.00-2.00 | ≤0.55 |
F90-F150 | ≥98.50 | 0.20-0.45 | ≤0.50 | ≥98.20 | 0.45-1.00 | ≤0.60 | ≥97.00 | 1.00-2.00 | ≤0.60 |
F180-F2000 | ≥98.50 | 0.20-0.45 | ≤0.50 | ≥97.80 | 0.45-1.00 | ≤0.70 | ≥96.50 | 1.00-2.00 | ≤0.70 |
PHYSICAL PROPERTIE
Basic minerals | Crystal size μm | True density g/cm3 | Bulk density g/ cm3 | Knoop hardness kg/mm2 |
α-Al2O3 | 600-2000 | ≥3.90 | 1.40-1.91 | 2200-2300 |
Application: The abrasive tools made of it feature excellent durability and high processing cleanness,which are suitable for
the precision grinding of the measuring tools,lathe main shafts,instruments and apparatus parts,threading workpieces and samplers,etc.
AvaialableSize:
F8 F10 F12 F14 F16 F20 F22 F24 F30 F36 F46 F54 F60 F70 F80 F90 F100 F120 F150 F180 F220 F240 F280 F320 F400 F500
F600 F800 F1000 F1200 F1500 F2000
JIS#8 JIS#10 JIS#12 JIS#14 JIS#16 JIS#20 JIS#24 JIS#30 JIS#36 JIS#46 JIS#54 JIS#60 JIS#80 JIS#100 JIS#120 JIS#150
JIS#180 JIS#220 JIS#240 JIS#280 JIS#320 JIS#400 JIS#600 JIS#800 JIS#1000 JIS#1200
JIS#1500 JIS#2000 JIS#2500 JIS#3000 JIS#4000 JIS#6000 JIS8000
Pink Fused Alumina is a specialized and unique type of fused alumina with a distinctive pink color. It offers exceptional toughness, high purity, and excellent thermal stability. This material finds its primary application in high-end grinding and polishing processes, ...
What Is Fused Alumina. Monocrystalline fused alumina is a range of abrasive materials and blasting media widely used in various industries. The product line includes brown fused alumina, white fused alumina, zirconia fused alumina, pink fused alumina, and black fused alumina. ...
Brown fused alumina is made of high-quality bauxite, anthracite, and iron filings. It is cooled and smelted at a high temperature by more than 2000 degrees in an electric arc. It is crushed and shaped by a jaw crusher and a ball mill. Description of Brown Fused Alumina for ...
Zirconia fused alumina is made of alumina and zirconia as raw materials and is smelted at a high temperature above 2200 ℃ in an electric arc furnace. Fused zirconia alumina is a kind of fused alumina containing 10% to 40% of zirconium dioxide (ZrO2). What is zirconia alumina ...
White fused alumina powder is made of industrial alumina powder, which is smelted in an arc at a high temperature of over 2000 degrees and then cooled. It is suitable for the manufacture of ceramics, resin-bonded abrasive tools, grinding, polishing, sandblasting, precision ...
zirconia abrasive 40 is made of high-purity alumina and fused zirconia as raw materials. It is smelted at a high temperature of 2250 ° C and formed by special processing technology and Barmac ball milling. It is of high quality, extremely hard, compact in structure and special ...
Zirconia alumina abrasive 25 is made of high-purity alumina and fused zirconia as raw materials. It is smelted at a high temperature of 2250 ° C and formed by special processing technology and Barmac ball milling. It is of high quality, extremely hard, compact in structure and ...
fused alumina zirconia is made of alumina and zirconia as raw materials and is smelted at a high temperature above 2200 ℃ in an electric arc furnace. Fused zirconia alumina is a kind of fused alumina containing 10% to 40% of zirconium dioxide (ZrO2). Zirconia Fused Alumina ...
As a kind of refractory materials, white fused alumina grit is generally used for aggregate and fine powder, because it has the characteristics of high refractoriness, wear resistance, corrosion resistance, etc., and it also has the characteristics of high load temperature and ...
White fused alumina abrasive for abrasive is suitable for surface beautification of various high-end products, crafts or hardware. After sandblasting, the surface is white without any impurities, eliminating the trouble of cleaning. White fused alumina fine powder can be used ...
