22kg light rail
Product Quick Detail
- Place Of Origin
- China
- Packaging
- Standard packaging
- Delivery
- 1-7 working days after the deal
Specifications
| size | Rail Height | Bottom Width | Head Width | Web Thickness |
Weight
kg/m |
| 8kg | 65 | 54 | 25 | 7 | 8.42 |
| 12kg | 69.85 | 69.85 | 38.1 | 7.54 | 12.2 |
| 15kg | 79.37 | 79.37 | 42.86 | 8.33 | 15.2 |
| 18kg | 90 | 80 | 40 | 10 | 18.06 |
| 22kg | 93.66 | 93.66 | 50.8 | 10.72 | 22.3 |
| 24kg | 107 | 92 | 51 | 10.9 | 24.95 |
| 30kg | 107.95 | 107.95 | 60.33 | 12.3 | 30.1 |
LightRail Knowledge:
Light rail is the weight less than or equal to 30kg per meter. The quality requirement of light rail is lower than heavy rail. So we only require to test the chemical component, the strength of extension, the hardness and the drop weight experiment.
Material: Q235B/55Q
Standard: GB11264-89, YB222-63
Length: 6-12m
Main Function:
Light rail is mainly orient ed and load bearing, it is used with the track wheel, to support the weight and change the direction of the cart.
Main Application:
The light rail is mainly used for the laying of temporary transportation lines and light locomotive lines for forest areas, mining areas, factories and construction sites.
