National 12P160 Mud Pump Ceramic Liner
Product Quick Detail
- FOB Price
- USD $500.00 / Piece
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- 12 pcs each iron tray
- Delivery
- 25 Days
Specifications
Gaomi Eastland Oilwell Machinery Co.,Ltd
Liner
Eastland offers zirconia liner, hy-chrome liner, chrome-plated liner and hardened liner matched performance and durability for in most drilling conditions.
Hy-chrome Liner
Eastland’s hy-chrome liner is made with a over 27% chrome iron inner sleeve in a forged steel outer shell. The bore hardness is 60 to 65 RC while the hull has high tensile strength of more than 90000psi. All hy-chrome liner are manufactured with an “HP” lip in case of inner sleeve slippage.
The service life of this liner is more than 800 hours under normal drilling conditions. Eastland’s hy-chrome liners are made for superior performance under tough corrosive and abrasive conditions.
Zirconia Liner
Zirconia liner(ZrO3) combines the strength of a forged steel outer shell with the abrasion and corrosion resistance of a ceramic inner sleeve.Zirconia liner is designed to adapt to deep oil reservoir, hard stratum and severe earthiness, offsore oil and natural gas exploitation. The service life of this type liner is over 4000 hours. Compared with hy-chrome liner and Alumina liner, zirconia liner possesses better impact strength, higher hardness with wear resistance, stronger erosion resistance, higher pressure resistance and finer surface finishes.
Chrome-plated Liner
Chrome-plated Liner is made from premium forged steel with chrome-coated core. The chrome-plated liners have hardening characteristics of 58 to 62 RC hardness.
Hardened Liner
Hardened Liner is made from premium seamless steel tube or premium forged steel, in which the bore is carburized and quenched, creating a hardened layer with hardness of 58 to 62 RC from abrasion and corrosion. It is honed to a mirror surface to prolong the life of pistons with lowest friction.
Gaomi Eastland Oilwell Machinery Co.,Ltd
Valve & Seat
Eastland offers a full range of popular used valve and seat to meet your different drilling demands.
Wing-guided Valve and Seat-Full Open
●Forged alloy construction
●Deep carburized wear surface
●Greater fluid flow
●Easier valve maintenance and seat pulling
Three-web and Four –web Design Valve and Seat
●Carburized premium ally steel
●Tested to withstand the harshest service condition
●Easy replacement to insert with a minimum of down time
●Long lasting service life
Avaliable Brands of Valve & Seat:
Bomco full open valve & Seat
Mud King three-web and four-web(cross-arm) valve & seat
Mud King 7FO-V1 Full Open valve & seat
NOV G2 full open valve & seat
Mission service master II valve & seat
Mission silver top valve & seat
Mission FK-1 valve & seat
Mission supreme valve & seat
Gardner Denver three-web valve & seat
Oilwell four-web valve & seat
Roughneck full open valve & seat
Southwest full open valve & seat
Baker double angle valve & seat
Baker plate type valve & seat
Baker WM full open valve & seat
Baker Mud Max full open valve & seat
Drillmec type valve & seat
Gaomi Eastland Oilwell Machinery Co.,Ltd
Piston
Eastland offers a full line of API taper pistons both for duplex and triplex mud pump. We have right options for your applications with versatile options of replaceable rubbers, urethane or bonded urethane pistons.
Bonded Urethane Piston
These pistons are constructed of urethane bonded to a solid metal hub, Double durometer urethane is designed to provide optimum performance in oil base or water base mud and high drilling pressure.
●Designed with harder, denser polyurethane construction
●High pressure mud pump service
●Maximum operating temperature is 180℉
●Extended service life
Replaceable Urethane Piston
These pistons are constructed of replaceable urethane mounted to a solid metal hub which is designed for high temperature drilling mud.
●Rated for all drilling conditions
●Maximum operating temperature is 230℉
●High pressure mud service
●Extended service life
Replaceable Rubber Piston
Replaceable rubber pistons are made with nitrile rubber to resist extrusion and abrasion.These pistons are fully interchangeable with most other manufactures products. Available
sizes are from 3″through 7-1/2″
| 3” | 3-1/2” | 4” | 4-1/2” | 5” | 5-1/2” | 6” | 6-1/4” | 6-1/2” | 6-3/4” | 7” | 7-1/4” | |
| Duplex | K | K | K | K | B | B | B | L | L | L | L | L |
| Triplex | K | K | K | K | B | B | B | L | L | L | L | L |
●High tensile strength
●Rated for all drilling conditions
●Maximum operating temperature is 250℉
●Extended service life
Avaliable Brands of Pistons:
Mission Supreme Piston
Mission White Ligtning Piston
Mission Blue Lightning Piston
Mission Green Duo Piston
Mission Flexlip Piston
Patriot double dual piston
Mud King Imperial piston
Mud King red thunder bonded piston
Mud King long-life bonded piston
Baker SPD piston
Gardner Denver duplex and triplex piston
- Country: China (Mainland)
- Business Type: Manufacturer
- Market:Americas,Asia,Middle East,European Union,Oceania,Emerging Markets
- Founded Year:2010
- Address:NO.5009,Yanzi Road,Gaomi,Weifang City
- Contact:Tony Zhao
