LED display
Product Quick Detail
- SQM
- 50
- 3.24SQM
- 10000
- Place Of Origin
- SHENZHEN
- Packaging
- Customized
- Delivery
- 15 Days
Specifications
Specifications
| Flexible led screen - M1 Specifications | |
| Model Name | M1 |
| Pixel Pitch | 37.5mm / 56.25mm (pixel pitch can be customized) |
| Pixel Configuration | 1*SMD3535 |
| Panel Size | 300*4800 mm / 450*7200mm (size can be customized) |
| Panel Resolution | 8*128 |
| Panel Weight | 4kg /sqm ; 2.4kg/sqm |
| Brightness | 1800 nits / 1200 nits (Nationstar SMD-RS-3535MWAR) |
| IP Rating(Front/Rear) | IP66 |
| Refresh Rate | 1000 - 3000 Hz |
| Transparency Rate | 70% / 80% |
| Scan Mode | Static |
| Max Power Consumption | 280 W/㎡ ; 100 W/㎡ |
| Color Processing | 16 bit |
| Viewing Angle（H/V） | 140°/110° |
| Operating Temperature | -40~45°C |
| Main Power Source | AC 100~240V; 50/60Hz |
| Input Voltage | 7.5V DC |
| Humidity | 10~90%RH |
| Life Time | 100,000 Hours |
