Toilet Paper Machine
Feature and function
1.Using PLC programmable control system
2,The man-machine dialoge control, display the production parametrs on screem
3.Jumbo roll paper is pneumatically loaded on machine, unwinding roll tensioncontrol device.
4.The rewinding process of the product is tight first and loose afterward, with itstension adjustable.
5.Punch length is adjustable.
6.Paper core replacement, glue spraying and paper cutting undergo automaticallyaccording to given sequence.
7.Embossing pattern is to be selected by clients.
8.The bearings,,electrical components and synchronous belts are using famous brand
9.According to the requirements of customers can do double embossing roll,and can assorted with rubber composite device to product the kitchen paper as also 1-3color printing equipment.
The technical parameters of fully automatic toilet paper machine
Model | 1575 1760 2200 2500 2800 |
The width of jumbo roll paper | 1750 2000 2150 2400 2700 |
The diameter of Jumbo Roll paper | Standard 1100mm,please specify the other sizes |
Roll quantity | 3a(can specify) |
Jumbo Roll paper core diameter | 3”(76.2mm)(please specify the other sizes) |
Parameter setting | PLC |
Production Speed | 0-180M/MIN |
Outside Dia | 90-135mm |
The finished paper core diameter | 25-50mm |
Mechanical drive | CVT Continuously Variable Transmission |
Pneumatic system | 3 air compressor,minimum pressure5kg/cm2pa(customer owned) |
Installed power | 3KW 380V,50HZ |
Embossing system | Single embossment,double embossment,steel to glue,steel to steel |
Dimension | 6.6×3.0×1.7 (L x W x H):(m) |
Machinery weight | 3T |
Intervals of punched holes | 100mm-120mm(please specify the other sizes) |
Paper core diameter size | 20-50mm |
Roll quantity | 1-3a jumbo roll paper can be ordered |
Gluing system | Convex glue |
Decorating adhesive system | According to the embossed pattern making(need to order) |
